Perforated Brass Sheets
| Brass Perforated Sheets, Straight Rows, 24" Wide Rolls
x Length in Feet * Denotes Staggered Rows |
|||||||
| Thickness (in.) | Width (in.) | Hole Diameter (in.) | Hole Center to Center (in.) | Open Area % | Part # | Price Per Linear Foot | Order Online |
|---|---|---|---|---|---|---|---|
| .016" | 24 | .016 | .026 | 30 | MS-9801 | $244.86 | Add to Order |
| .016" | 24 | .016 | .035 | 22 | MS-9814* | $143.54 | Add to Order |
| .016" | 24 | .020 | .030 | 20 | MS-9802 | $202.98 | Add to Order |
| .016" | 24 | .020 | .040 | 22 | MS-9815* | $100.82 | Add to Order |
| .016" | 24 | .024 | .044 | 30 | MS-9803 | $132.08 | Add to Order |
| .016" | 24 | .027 | .050 | 23 | MS-9804 | $164.18 | Add to Order |
| .016" | 24 | .033 | .055 | 23 | MS-9805 | $117.14 | Add to Order |
| .016" | 24 | .038 | .050 | 45 | MS-9806 | $152.58 | Add to Order |
| .016" | 24 | .040 | .066 | 29 | MS-9807 | $142.82 | Add to Order |
| .016" | 24 | .045 | .066 | 37 | MS-9808 | $151.12 | Add to Order |
| .016" | 24 | .057 | .086 | 34 | MS-9809 | $142.86 | Add to Order |
| .016" | 24 | .065 | .100 | 33 | MS-9810 | $122.72 | Add to Order |
| .016" | 24 | .079 | .110 | 41 | MS-9811 | $119.48 | Add to Order |
| .016" | 24 | .103 | .132 | 48 | MS-9812 | $91.30 | Add to Order |
| .016" | 24 | .138 | .188 | 43 | MS-9813 | $114.86 | Add to Order |
| Rev. 05-23, 09-22, 02-22, 06-21 | |||||||
