JIS Class 10.9 Zinc Plated Flange Bolts
High Strength, RH Full Threads, SAE J429
| JIS High Strength Zinc Plated Class 10.9 Steel Flange Head Bolts Fully Threaded | ||||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Flange Diameter | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-5421 | M6 x 1 | 12mm | 10mm | 6mm | 14mm | 100 | $34.99 | Add to Order |
| Bolt-5422 | M6 x 1 | 16mm | 10mm | 6mm | 14mm | 100 | $35.07 | Add to Order |
| Bolt-5423 | M6 x 1 | 20mm | 10mm | 6mm | 14mm | 100 | $26.29 | Add to Order |
| Bolt-5424 | M6 x 1 | 25mm | 10mm | 6mm | 14mm | 100 | $42.04 | Add to Order |
| Bolt-5428 | M8 x 1.25 | 12mm | 12mm | 8mm | 17.5mm | 50 | $27.97 | Add to Order |
| Bolt-5429 | M8 x 1.25 | 16mm | 12mm | 8mm | 17.5mm | 50 | $31.46 | Add to Order |
| Bolt-5430 | M8 x 1.25 | 20mm | 12mm | 8mm | 17.5mm | 50 | $38.56 | Add to Order |
| Bolt-5431 | M8 x 1.25 | 25mm | 12mm | 8mm | 17.5mm | 50 | $42.00 | Add to Order |
| Bolt-5432 | M8 x 1.25 | 30mm | 12mm | 8mm | 17.5mm | 50 | $42.04 | Add to Order |
| Bolt-5438 | M10 x 1.5 | 16mm | 14mm | 10mm | 21mm | 25 | $26.27 | Add to Order |
| Bolt-5439 | M10 x 1.5 | 20mm | 14mm | 10mm | 21mm | 25 | $72.77 | Add to Order |
| Bolt-5440 | M10 x 1.5 | 25mm | 14mm | 10mm | 21mm | 25 | $24.82 | Add to Order |
| Bolt-5441 | M10 x 1.5 | 30mm | 14mm | 10mm | 21mm | 25 | $46.89 | Add to Order |
| Bolt-5442 | M10 x 1.5 | 35mm | 14mm | 10mm | 21mm | 25 | $45.95 | Add to Order |
| Rev. 03-25, 04-23, 11-22, 02-22 | ||||||||
| JIS High Strength Zinc Plated Class 10.9 Steel Flange Head Bolts Partially Threaded | |||||||||
| Part # | Thread Length | Thread Size | Overall Length | Head Width | Head Height | Flange Diameter | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| Bolt-5425 | 18 to Full | M6 x 1 | 30mm | 10mm | 6mm | 14mm | 50 | $24.51 | Add to Order |
| Bolt-5426 | 18 to 23 | M6 x 1 | 35mm | 10mm | 6mm | 14mm | 100 | $56.11 | Add to Order |
| Bolt-5427 | 18 to 23 | M6 x 1 | 40mm | 10mm | 6mm | 14mm | 50 | $28.01 | Add to Order |
| Bolt-5433 | 22 to Full | M8 x 1.25 | 35mm | 12mm | 8mm | 17.5mm | 25 | $22.74 | Add to Order |
| Bolt-5434 | 22 to 29 | M8 x 1.25 | 40mm | 12mm | 8mm | 17.5mm | 25 | $24.51 | Add to Order |
| Bolt-5435 | 22 to 29 | M8 x 1.25 | 45mm | 12mm | 8mm | 17.5mm | 25 | $27.99 | Add to Order |
| Bolt-5436 | 22 to 29 | M8 x 1.25 | 50mm | 12mm | 8mm | 17.5mm | 25 | $29.76 | Add to Order |
| Bolt-5437 | 22 to 29 | M8 x 1.25 | 60mm | 12mm | 8mm | 17.5mm | 25 | $31.50 | Add to Order |
| Bolt-5443 | 26 to Full | M10 x 1.25 | 40mm | 14mm | 10mm | 21mm | 20 | $33.39 | Add to Order |
| Bolt-5444 | 26 to 34 | M10 x 1.25 | 45mm | 14mm | 10mm | 21mm | 20 | $36.37 | Add to Order |
| Bolt-5445 | 26 to 34 | M10 x 1.25 | 50mm | 14mm | 10mm | 21mm | 20 | $37.84 | Add to Order |
| Bolt-5446 | 26 to 34 | M10 x 1.25 | 60mm | 14mm | 10mm | 21mm | 25 | $94.40 | Add to Order |
| Bolt-5447 | 26 to 34 | M10 x 1.25 | 70mm | 14mm | 10mm | 21mm | 10 | $23.63 | Add to Order |
| Rev. 03-25, 08-23, 04-23, 11-22 | |||||||||
