Class 8.8 Metric Zinc Yellow Chromate Plated Steel Bolts
Class 8.8, RH Threads, Fully Threaded, JIS B 1180
| Metric Class 8.8 Zinc Yellow Chromate Plated Steel Bolts | |||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| Bolt-2827 | M8 x 1.25 | 12mm | 12mm | 5.5mm | 20 | $56.53 | Add to Order |
| Bolt-2828 | M8 x 1.25 | 16mm | 12mm | 5.5mm | 20 | $57.20 | Add to Order |
| Bolt-2829 | M8 x 1.25 | 20mm | 12mm | 5.5mm | 20 | $62.16 | Add to Order |
| Bolt-2830 | M8 x 1.25 | 25mm | 12mm | 5.5mm | 10 | $32.51 | Add to Order |
| Bolt-2831 | M8 x 1.25 | 30mm | 12mm | 5.5mm | 10 | $33.43 | Add to Order |
| Bolt-2832 | M8 x 1.25 | 35mm | 12mm | 5.5mm | 10 | $34.73 | Add to Order |
| Bolt-2833 | M8 x 1.25 | 40mm | 12mm | 5.5mm | 10 | $35.57 | Add to Order |
| Bolt-2834 | M8 x 1.25 | 45mm | 12mm | 5.5mm | 10 | $37.80 | Add to Order |
| Bolt-2835 | M8 x 1.25 | 50mm | 12mm | 5.5mm | 10 | $41.29 | Add to Order |
| Bolt-2836 | M8 x 1.25 | 60mm | 12mm | 5.5mm | 10 | $44.39 | Add to Order |
| Bolt-2837 | M8 x 1.25 | 70mm | 12mm | 5.5mm | 10 | $51.79 | Add to Order |
| Bolt-2838 | M10 x 1.25 | 20mm | 14mm | 7mm | 10 | $54.60 | Add to Order |
| Bolt-2839 | M10 x 1.25 | 25mm | 14mm | 7mm | 10 | $59.47 | Add to Order |
| Bolt-2840 | M10 x 1.25 | 30mm | 14mm | 7mm | 5 | $30.45 | Add to Order |
| Bolt-2841 | M10 x 1.25 | 35mm | 14mm | 7mm | 5 | $31.14 | Add to Order |
| Bolt-2842 | M10 x 1.25 | 40mm | 14mm | 7mm | 5 | $31.21 | Add to Order |
| Bolt-2843 | M10 x 1.25 | 45mm | 14mm | 7mm | 5 | $32.57 | Add to Order |
| Bolt-2844 | M10 x 1.25 | 50mm | 14mm | 7mm | 5 | $36.06 | Add to Order |
| Bolt-2845 | M10 x 1.25 | 60mm | 14mm | 7mm | 5 | $36.39 | Add to Order |
| Bolt-2846 | M10 x 1.25 | 70mm | 14mm | 7mm | 5 | $37.46 | Add to Order |
| Rev. 04-23, 02-23, 11-22, 02-22 | |||||||
| Class 8.8 Zinc Yellow Chromate Steel Flange Head Bolts | ||||||||
| Part # | Thread Length | Thread Size | Overall Length | Head Width | Head Height | Flange Diameter | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|---|
| Bolt-5396 | 9 to Full | M6 x 1 | 12mm | 10mm | 6.6mm | 14.2mm | 100 | $21.04 |
| Bolt-5397 | 13 to Full | M6 x 1 | 16mm | 10mm | 6.6mm | 14.2mm | 100 | $34.99 |
| Bolt-5398 | 17 to Full | M6 x 1 | 20mm | 10mm | 6.6mm | 14.2mm | 100 | $35.03 |
| Bolt-5399 | 18 to 23 | M6 x 1 | 25mm | 10mm | 6.6mm | 14.2mm | 100 | $42.04 |
| Bolt-5400 | 18 to 23 | M6 x 1 | 30mm | 10mm | 6.6mm | 14.2mm | 100 | $35.11 |
| Bolt-5401 | 12 to Full | M8 x 1.25 | 16mm | 13mm | 8.1mm | 18mm | 50 | $31.52 |
| Bolt-5402 | 16 to Full | M8 x 1.25 | 20mm | 13mm | 8.1mm | 18mm | 50 | $35.01 |
| Bolt-5403 | 21 to Full | M8 x 1.25 | 25mm | 13mm | 8.1mm | 18mm | 50 | $34.99 |
| Bolt-5404 | 22 to Full | M8 x 1.25 | 30mm | 13mm | 8.1mm | 18mm | 100 | $74.19 |
| Bolt-5405 | 22 to 29 | M8 x 1.25 | 35mm | 13mm | 8.1mm | 18mm | 100 | $90.97 |
| Bolt-5406 | 22 to 29 | M8 x 1.25 | 40mm | 13mm | 8.1mm | 18mm | 100 | $84.00 |
| Bolt-5407 | 15 to Full | M10 x 1.5 | 20mm | 15mm | 9.2mm | 22.3mm | 25 | $28.01 |
| Bolt-5408 | 20 to Full | M10 x 1.5 | 25mm | 15mm | 9.2mm | 22.3mm | 25 | $29.74 |
| Bolt-5409 | 25 to Full | M10 x 1.5 | 30mm | 15mm | 9.2mm | 22.3mm | 25 | $26.27 |
| Bolt-5410 | 26 to Full | M10 x 1.5 | 35mm | 15mm | 9.2mm | 22.3mm | 25 | $28.01 |
| Bolt-5411 | 26 to 34 | M10 x 1.5 | 40mm | 15mm | 9.2mm | 22.3mm | 20 | $30.79 |
| Bolt-5412 | 26 to 34 | M10 x 1.5 | 45mm | 15mm | 9.2mm | 22.3mm | 20 | $33.64 |
| Bolt-5413 | 26 to 34 | M10 x 1.5 | 50mm | 15mm | 9.2mm | 22.3mm | 20 | $36.41 |
| Bolt-5414 | 19 to Full | M12 x 1.75 | 25mm | 16mm | 11.5mm | 26.6mm | 20 | $30.79 |
| Bolt-5415 | 24 to Full | M12 x 1.75 | 30mm | 16mm | 11.5mm | 26.6mm | 20 | $32.21 |
| Bolt-5416 | 29.7 to Full | M12 x 1.75 | 35mm | 16mm | 11.5mm | 26.6mm | 20 | $33.64 |
| Bolt-5417 | 30 to Full | M12 x 1.75 | 40mm | 16mm | 11.5mm | 26.6mm | 20 | $37.84 |
| Bolt-5418 | 30 to 39 | M12 x 1.75 | 45mm | 16mm | 11.5mm | 26.6mm | 20 | $40.61 |
| Bolt-5419 | 30 to 39 | M12 x 1.75 | 50mm | 16mm | 11.5mm | 26.6mm | 10 | $21.00 |
| Bolt-5420 | 30 to 39 | M12 x 1.75 | 60mm | 16mm | 11.5mm | 26.6mm | 10 | $23.79 |
| Rev. 08-23, 04-23, 11-22, 05-22 | ||||||||
