Metric Din 960 Zinc Plated Steel Hex Head Bolts
Class 8.8, Partially Threaded, Right Hand Threads, DIN 960
Metric Medium Strength Zinc Plated Steel Hex Head Bolts
| Part # | Thread Size | Partial Thread | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-2518 | M8 x 1 | 22 to 29 | 40mm | 13mm | 5.3mm | 25 | $29.53 | Add to Order |
| Bolt-2520 | M8 x 1 | 22 to 29 | 45mm | 13mm | 5.3mm | 20 | $38.39 | Add to Order |
| Bolt-2522 | M8 x 1 | 22 to 29 | 50mm | 13mm | 5.3mm | 25 | $31.50 | Add to Order |
| Bolt-2523 | M8 x 1 | 22 to 29 | 55mm | 13mm | 5.3mm | 20 | $32.59 | Add to Order |
| Bolt-2524 | M8 x 1 | 22 to 29 | 60mm | 13mm | 5.3mm | 20 | $37.34 | Add to Order |
| Bolt-2525 | M8 x 1 | 22 to 29 | 80mm | 13mm | 5.3mm | 20 | $72.16 | Add to Order |
| Bolt-2526 | M8 x 1 | 22 to 29 | 100mm | 13mm | 5.3mm | 10 | $39.69 | Add to Order |
| Bolt-2567 | M10 x 1.25 | 26 to 34 | 35mm | 17mm | 6.4mm | 10 | $28.58 | Add to Order |
| Bolt-2569 | M10 x 1.25 | 26 to 34 | 40mm | 17mm | 6.4mm | 20 | $45.86 | Add to Order |
| Bolt-2571 | M10 x 1.25 | 26 to 34 | 45mm | 17mm | 6.4mm | 20 | $46.37 | Add to Order |
| Bolt-2573 | M10 x 1.25 | 26 to 34 | 50mm | 17mm | 6.4mm | 20 | $26.46 | Add to Order |
| Bolt-2574 | M10 x 1.25 | 26 to 34 | 55mm | 17mm | 6.4mm | 10 | $48.70 | Add to Order |
| Bolt-2576 | M10 x 1.25 | 26 to 34 | 60mm | 17mm | 6.4mm | 10 | $18.69 | Add to Order |
| Bolt-2577 | M10 x 1.25 | 26 to 34 | 65mm | 17mm | 6.4mm | 10 | $31.29 | Add to Order |
| Bolt-2578 | M10 x 1.25 | 26 to 34 | 70mm | 17mm | 6.4mm | 10 | $19.19 | Add to Order |
| Bolt-2579 | M10 x 1.25 | 26 to 34 | 75mm | 17mm | 6.4mm | 10 | $17.49 | Add to Order |
| Bolt-2580 | M10 x 1.25 | 26 to 34 | 80mm | 17mm | 6.4mm | 10 | $18.69 | Add to Order |
| Bolt-2581 | M10 x 1.25 | 26 to 34 | 90mm | 17mm | 6.4mm | 10 | $37.13 | Add to Order |
| Bolt-2582 | M10 x 1.25 | 26 to 34 | 100mm | 17mm | 6.4mm | 10 | $43.34 | Add to Order |
| Bolt-2583 | M10 x 1.25 | 26 to 34 | 110mm | 17mm | 6.4mm | 4 | $33.35 | Add to Order |
| Bolt-2584 | M10 x 1.25 | 26 to 34 | 120mm | 17mm | 6.4mm | 5 | $32.09 | Add to Order |
| Bolt-2591 | M10 x 1 | 26 to 34 | 40mm | 17mm | 6.4mm | 20 | $40.49 | Add to Order |
| Bolt-2593 | M10 x 1 | 26 to 34 | 45mm | 17mm | 6.4mm | 20 | $49.18 | Add to Order |
| Bolt-2595 | M10 x 1 | 26 to 34 | 50mm | 17mm | 6.4mm | 10 | $31.29 | Add to Order |
| Bolt-2597 | M10 x 1 | 26 to 34 | 60mm | 17mm | 6.4mm | 10 | $40.99 | Add to Order |
| Bolt-2598 | M10 x 1 | 26 to 34 | 80mm | 17mm | 6.4mm | 10 | $49.81 | Add to Order |
| Bolt-2599 | M10 x 1 | 26 to 34 | 100mm | 17mm | 6.4mm | 5 | $30.24 | Add to Order |
| Bolt-2636 | M12 x 1.5 | 30 to 39 | 40mm | 19mm | 7.5mm | 10 | $50.15 | Add to Order |
| Bolt-2639 | M12 x 1.5 | 30 to 39 | 50mm | 19mm | 7.5mm | 10 | $17.49 | Add to Order |
| Bolt-2640 | M12 x 1.5 | 30 to 39 | 55mm | 19mm | 7.5mm | 10 | $49.69 | Add to Order |
| Bolt-2642 | M12 x 1.5 | 30 to 39 | 60mm | 19mm | 7.5mm | 10 | $26.10 | Add to Order |
| Bolt-2643 | M12 x 1.5 | 30 to 39 | 65mm | 19mm | 7.5mm | 10 | $21.32 | Add to Order |
| Bolt-2644 | M12 x 1.5 | 30 to 39 | 70mm | 19mm | 7.5mm | 5 | $21.99 | Add to Order |
| Bolt-2645 | M12 x 1.5 | 30 to 39 | 75mm | 19mm | 7.5mm | 5 | $35.05 | Add to Order |
| Bolt-2646 | M12 x 1.5 | 30 to 39 | 80mm | 19mm | 7.5mm | 10 | $27.01 | Add to Order |
| Bolt-2647 | M12 x 1.5 | 30 to 39 | 90mm | 19mm | 7.5mm | 5 | $33.75 | Add to Order |
| Bolt-2648 | M12 x 1.5 | 30 to 39 | 100mm | 19mm | 7.5mm | 5 | $24.68 | Add to Order |
| Bolt-2654 | M12 x 1.25 | 30 to 39 | 40mm | 19mm | 7.5mm | 10 | $50.65 | Add to Order |
| Bolt-2656 | M12 x 1.25 | 30 to 39 | 45mm | 19mm | 7.5mm | 10 | $31.63 | Add to Order |
| Bolt-2658 | M12 x 1.25 | 30 to 39 | 50mm | 19mm | 7.5mm | 10 | $17.87 | Add to Order |
| Bolt-2659 | M12 x 1.25 | 30 to 39 | 55mm | 19mm | 7.5mm | 10 | $41.79 | Add to Order |
| Bolt-2661 | M12 x 1.25 | 30 to 39 | 60mm | 19mm | 7.5mm | 10 | $20.24 | Add to Order |
| Bolt-2662 | M12 x 1.25 | 30 to 39 | 65mm | 19mm | 7.5mm | 5 | $31.35 | Add to Order |
| Bolt-2663 | M12 x 1.25 | 30 to 39 | 70mm | 19mm | 7.5mm | 10 | $22.45 | Add to Order |
| Bolt-2664 | M12 x 1.25 | 30 to 39 | 75mm | 19mm | 7.5mm | 10 | $51.03 | Add to Order |
| Bolt-2665 | M12 x 1.25 | 30 to 39 | 80mm | 19mm | 7.5mm | 10 | $24.80 | Add to Order |
| Bolt-2666 | M12 x 1.25 | 30 to 39 | 90mm | 19mm | 7.5mm | 5 | $28.27 | Add to Order |
| Bolt-2667 | M12 x 1.25 | 30 to 39 | 100mm | 19mm | 7.5mm | 5 | $28.75 | Add to Order |
| Bolt-2668 | M12 x 1.25 | 30 to 39 | 110mm | 19mm | 7.5mm | 5 | $19.70 | Add to Order |
| Bolt-2669 | M12 x 1.25 | 30 to 39 | 120mm | 19mm | 7.5mm | 4 | $29.74 | Add to Order |
| Bolt-2700 | M14 x 1.5 | 34 to 44 | 45mm | 22mm | 8.8mm | 4 | $34.69 | Add to Order |
| Bolt-2702 | M14 x 1.5 | 34 to 44 | 50mm | 22mm | 8.8mm | 4 | $35.20 | Add to Order |
| Bolt-2705 | M14 x 1.5 | 34 to 44 | 60mm | 22mm | 8.8mm | 3 | $27.97 | Add to Order |
| Bolt-2706 | M14 x 1.5 | 34 to 44 | 65mm | 22mm | 8.8mm | 3 | $28.98 | Add to Order |
| Bolt-2707 | M14 x 1.5 | 34 to 44 | 70mm | 22mm | 8.8mm | 3 | $28.35 | Add to Order |
| Bolt-2708 | M14 x 1.5 | 34 to 44 | 80mm | 22mm | 8.8mm | 3 | $31.75 | Add to Order |
| Bolt-2709 | M14 x 1.5 | 34 to 44 | 90mm | 22mm | 8.8mm | 3 | $35.72 | Add to Order |
| Bolt-2710 | M14 x 1.5 | 34 to 44 | 100mm | 22mm | 8.8mm | 3 | $37.93 | Add to Order |
| Bolt-2711 | M14 x 1.5 | 34 to 44 | 120mm | 22mm | 8.8mm | 3 | $37.99 | Add to Order |
| Bolt-2748 | M16 x 1.5 | 38 to 48 | 50mm | 24mm | 10mm | 3 | $37.11 | Add to Order |
| Bolt-2750 | M16 x 1.5 | 38 to 48 | 60mm | 24mm | 10mm | 4 | $31.33 | Add to Order |
| Bolt-2751 | M16 x 1.5 | 38 to 48 | 70mm | 24mm | 10mm | 4 | $34.44 | Add to Order |
| Bolt-2752 | M16 x 1.5 | 38 to 48 | 80mm | 24mm | 10mm | 4 | $38.22 | Add to Order |
| Bolt-2753 | M16 x 1.5 | 38 to 48 | 100mm | 24mm | 10mm | 3 | $31.69 | Add to Order |
