Class 8.8 Serrated Flange Head Cap Screws
| Zinc Plated Class 8.8 Cap Screws, RH Threads, Serrated & Fully Threaded, SAE J429 | ||||||||
| Part # | Thread Size | Overall Length | Flange Diameter | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-338 | M6 x 1 | 12mm | 14.2mm | 10mm | 6.6mm | 100 | $29.99 | Add to Order |
| Bolt-339 | M6 x 1 | 16mm | 14.2mm | 10mm | 6.6mm | 100 | $37.46 | Add to Order |
| Bolt-340 | M6 x 1 | 20mm | 14.2mm | 10mm | 6.6mm | 100 | $37.46 | Add to Order |
| Bolt-341 | M6 x 1 | 25mm | 14.2mm | 10mm | 6.6mm | 100 | $37.51 | Add to Order |
| Bolt-342 | M6 x 1 | 30mm | 14.2mm | 10mm | 6.6mm | 100 | $37.55 | Add to Order |
| Bolt-343 | M6 x 1 | 35mm | 14.2mm | 10mm | 6.6mm | 100 | $44.98 | Add to Order |
| Bolt-344 | M6 x 1 | 40mm | 14.2mm | 10mm | 6.6mm | 100 | $44.98 | Add to Order |
| Bolt-345 | M8 x 1.25 | 16mm | 18mm | 13mm | 8.1mm | 50 | $30.01 | Add to Order |
| Bolt-346 | M8 x 1.25 | 20mm | 18mm | 13mm | 8.1mm | 50 | $33.75 | Add to Order |
| Bolt-347 | M8 x 1.25 | 25mm | 18mm | 13mm | 8.1mm | 50 | $37.49 | Add to Order |
| Bolt-348 | M8 x 1.25 | 30mm | 18mm | 13mm | 8.1mm | 50 | $37.49 | Add to Order |
| Bolt-349 | M8 x 1.25 | 35mm | 18mm | 13mm | 8.1mm | 50 | $41.20 | Add to Order |
| Bolt-350 | M8 x 1.25 | 40mm | 18mm | 13mm | 8.1mm | 50 | $41.20 | Add to Order |
| Bolt-351 | M10 x 1.5 | 20mm | 22.3mm | 15mm | 9.2mm | 25 | $28.12 | Add to Order |
| Bolt-352 | M10 x 1.5 | 25mm | 22.3mm | 15mm | 9.2mm | 25 | $30.01 | Add to Order |
| Bolt-353 | M10 x 1.5 | 30mm | 22.3mm | 15mm | 9.2mm | 25 | $28.13 | Add to Order |
| Bolt-354 | M10 x 1.5 | 35mm | 22.3mm | 15mm | 9.2mm | 25 | $30.01 | Add to Order |
| Bolt-355 | M10 x 1.5 | 40mm | 22.3mm | 15mm | 9.2mm | 25 | $33.75 | Add to Order |
| Bolt-356 | M12 x 1.75 | 30mm | 26.6mm | 16mm | 11.5mm | 20 | $37.42 | Add to Order |
| Bolt-357 | M12 x 1.75 | 35mm | 26.6mm | 16mm | 11.5mm | 20 | $42.00 | Add to Order |
| Bolt-358 | M12 x 1.75 | 40mm | 26.6mm | 16mm | 11.5mm | 20 | $43.64 | Add to Order |
| Rev. 04-23, 11-22, 02-22, 07-21 | ||||||||
