Class 8.8 Steel Left Hand Cap Screws
Class 8.8, Uncoated, Fully Threaded, LH Threads
| Class 8.8 Steel Left Hand Bolts | ||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Price Each | Order Online |
|---|---|---|---|---|---|---|
| Bolt-5668 | M6 x 1 | 12mm | 10mm | 4mm | $50.65 | Add to Order |
| Bolt-5669 | M6 x 1 | 16mm | 10mm | 4mm | $50.93 | Add to Order |
| Bolt-5670 | M6 x 1 | 20mm | 10mm | 4mm | $51.20 | Add to Order |
| Bolt-5671 | M6 x 1 | 25mm | 10mm | 4mm | $51.49 | Add to Order |
| Bolt-5672 | M6 x 1 | 30mm | 10mm | 4mm | $51.83 | Add to Order |
| Bolt-5673 | M8 x 1.25 | 16mm | 13mm | 5.3mm | $51.41 | Add to Order |
| Bolt-5674 | M8 x 1.25 | 20mm | 13mm | 5.3mm | $54.45 | Add to Order |
| Bolt-5675 | M8 x 1.25 | 25mm | 13mm | 5.3mm | $54.77 | Add to Order |
| Bolt-5676 | M8 x 1.25 | 30mm | 13mm | 5.3mm | $55.13 | Add to Order |
| Bolt-5677 | M8 x 1.25 | 35mm | 13mm | 5.3mm | $55.46 | Add to Order |
| Bolt-5678 | M8 x 1.25 | 40mm | 13mm | 5.3mm | $55.90 | Add to Order |
| Bolt-5679 | M10 x 1.5 | 20mm | 17mm | 6.4mm | $61.57 | Add to Order |
| Bolt-5680 | M10 x 1.5 | 25mm | 17mm | 6.4mm | $62.08 | Add to Order |
| Bolt-5681 | M10 x 1.5 | 30mm | 17mm | 6.4mm | $62.52 | Add to Order |
| Bolt-5682 | M10 x 1.5 | 35mm | 17mm | 6.4mm | $63.06 | Add to Order |
| Bolt-5683 | M10 x 1.5 | 40mm | 17mm | 6.4mm | $63.53 | Add to Order |
| Bolt-5684 | M12 x 1.75 | 25mm | 19mm | 7.5mm | $63.63 | Add to Order |
| Bolt-5685 | M12 x 1.75 | 30mm | 19mm | 7.5mm | $64.18 | Add to Order |
| Bolt-5686 | M12 x 1.75 | 35mm | 19mm | 7.5mm | $64.62 | Add to Order |
| Bolt-5687 | M12 x 1.75 | 40mm | 19mm | 7.5mm | $65.12 | Add to Order |
| Rev. 03-25, 11-22, 02-22 | ||||||
