10.9 Zinc-Plated Metric Steel Bolts
Class 10.9, RH Threads, DIN 933; ISO 4017
| 10.9 Zinc Plated Hex Head Cap Screw / Bolt | |||||||
| Part # | Thread Size (mm) | Ptich | Length mm | Hex Size (mm) | Full or Partial | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|
| Bolt-5942 | M5 | 0.8 | 12 | 8 | FT | 50 | $88.97 |
| Bolt-5943 | M5 | 0.8 | 16 | 8 | FT | 50 | $128.20 |
| Bolt-5944 | M5 | 0.8 | 20 | 8 | FT | 50 | $154.24 |
| Bolt-5945 | M5 | 0.8 | 25 | 8 | FT | 50 | $166.14 |
| Bolt-5946 | M5 | 0.8 | 30 | 8 | PT | 50 | $332.48 |
| Bolt-5947 | M5 | 0.8 | 35 | 8 | PT | 50 | $360.36 |
| Bolt-5948 | M5 | 0.8 | 40 | 8 | PT | 50 | $176.98 |
| Bolt-5949 | M5 | 0.8 | 45 | 8 | PT | 50 | $154.35 |
| Bolt-5950 | M5 | 0.8 | 50 | 8 | PT | 50 | $483.62 |
| Bolt-5951 | M5 | 0.8 | 60 | 8 | PT | 50 | $954.56 |
| Bolt-5952 | M5 | 0.8 | 65 | 8 | PT | 50 | $917.37 |
| Bolt-5953 | M5 | 0.8 | 70 | 8 | PT | 50 | $863.17 |
| Bolt-5954 | M6 | 1.0 | 12 | 10 | FT | 100 | $27.00 |
| Bolt-5955 | M6 | 1.0 | 14 | 10 | FT | 50 | $18.41 |
| Bolt-5956 | M6 | 1.0 | 16 | 10 | FT | 100 | $27.86 |
| Bolt-5957 | M6 | 1.0 | 18 | 10 | PT | 100 | $29.23 |
| Bolt-5958 | M6 | 1.0 | 20 | 10 | FT | 100 | $34.65 |
| Bolt-5959 | M6 | 1.0 | 25 | 10 | FT | 100 | $35.03 |
| Bolt-5960 | M6 | 1.0 | 30 | 10 | PT | 100 | $34.79 |
| Bolt-5961 | M6 | 1.0 | 35 | 10 | PT | 100 | $40.14 |
| Bolt-5962 | M6 | 1.0 | 40 | 10 | PT | 100 | $46.33 |
| Bolt-5963 | M6 | 1.0 | 45 | 10 | PT | 100 | $50.71 |
| Bolt-5964 | M6 | 1.0 | 50 | 10 | PT | 100 | $56.43 |
| Bolt-5965 | M6 | 1.0 | 60 | 10 | PT | 25 | $18.68 |
| Bolt-5966 | M6 | 1.0 | 70 | 10 | PT | 50 | $35.14 |
| Bolt-5967 | M6 | 1.0 | 80 | 10 | PT | 25 | $19.33 |
| Bolt-5968 | M6 | 1.0 | 100 | 10 | PT | 25 | $25.31 |
| Bolt-5969 | M8 | 1.25 | 30 | 13 | FT | 25 | $15.30 |
| Bolt-5970 | M8 | 1.25 | 12 | 13 | FT | 50 | $184.79 |
| Bolt-5971 | M8 | 1.25 | 14 | 13 | FT | 50 | $20.63 |
| Bolt-5972 | M8 | 1.25 | 16 | 13 | PT | 100 | $42.12 |
| Bolt-5973 | M8 | 1.25 | 16 | 13 | FT | 25 | $10.53 |
| Bolt-5974 | M8 | 1.25 | 18 | 13 | FT | 50 | $45.41 |
| Bolt-5975 | M8 | 1.25 | 20 | 13 | FT | 100 | $53.62 |
| Bolt-5976 | M8 | 1.25 | 25 | 13 | FT | 100 | $47.05 |
| Bolt-5977 | M8 | 1.25 | 35 | 13 | PT | 25 | $17.08 |
| Bolt-5978 | M8 | 1.25 | 40 | 13 | PT | 25 | $18.22 |
| Bolt-5979 | M8 | 1.25 | 45 | 13 | PT | 25 | $18.86 |
| Bolt-5980 | M8 | 1.25 | 50 | 13 | PT | 25 | $22.57 |
| Bolt-5981 | M8 | 1.25 | 55 | 13 | PT | 10 | $13.54 |
| Bolt-5982 | M8 | 1.25 | 60 | 13 | PT | 25 | $24.32 |
| Bolt-5983 | M8 | 1.25 | 65 | 13 | FT | 10 | $14.38 |
| Bolt-5984 | M8 | 1.25 | 70 | 13 | PT | 10 | $17.15 |
| Bolt-5985 | M8 | 1.25 | 75 | 13 | FT | 10 | $16.09 |
| Bolt-5986 | M8 | 1.25 | 80 | 13 | FT | 10 | $16.11 |
| Bolt-5987 | M8 | 1.25 | 80 | 13 | PT | 25 | $34.09 |
| Bolt-5988 | M8 | 1.25 | 100 | 13 | FT | 10 | $18.79 |
| Bolt-5989 | M10 | 1.5 | 16 | 17 | FT | 50 | $30.98 |
| Bolt-5990 | M10 | 1.5 | 20 | 17 | FT | 50 | $42.19 |
| Bolt-5991 | M10 | 1.5 | 25 | 17 | FT | 50 | $40.14 |
| Bolt-5992 | M10 | 1.5 | 30 | 17 | FT | 25 | $24.57 |
| Bolt-5993 | M10 | 1.5 | 35 | 16 | PT | 25 | $25.47 |
| Bolt-5994 | M10 | 1.5 | 35 | 17 | FT | 100 | $117.27 |
| Bolt-5995 | M10 | 1.5 | 40 | 16 | PT | 25 | $24.46 |
| Bolt-5996 | M10 | 1.5 | 45 | 16 | PT | 25 | $27.77 |
| Bolt-5997 | M10 | 1.5 | 50 | 16 | PT | 25 | $33.07 |
| Bolt-5998 | M10 | 1.5 | 55 | 16 | PT | 25 | $36.88 |
| Bolt-5999 | M10 | 1.5 | 60 | 16 | PT | 25 | $39.15 |
| Bolt-6000 | M10 | 1.5 | 65 | 16 | PT | 25 | $34.43 |
| Bolt-6001 | M10 | 1.5 | 70 | 16 | PT | 25 | $78.66 |
| Bolt-6002 | M10 | 1.5 | 75 | 16 | PT | 25 | $46.67 |
| Bolt-6003 | M10 | 1.5 | 80 | 16 | PT | 25 | $48.82 |
| Bolt-6004 | M10 | 1.5 | 90 | 16 | PT | 25 | $56.43 |
| Bolt-6005 | M10 | 1.5 | 100 | 17 | PT | 25 | $58.23 |
| Bolt-6006 | M10 | 1.5 | 130 | 16 | PT | 5 | $16.22 |
| Bolt-6007 | M12 | 1.75 | 20 | 19 | FT | 25 | $25.99 |
| Bolt-6008 | M12 | 1.75 | 25 | 19 | FT | 25 | $32.11 |
| Bolt-6009 | M12 | 1.75 | 30 | 19 | FT | 25 | $34.04 |
| Bolt-6010 | M12 | 1.75 | 35 | 19 | FT | 25 | $28.91 |
| Bolt-6011 | M12 | 1.75 | 35 | 19 | FT | 10 | $16.00 |
| Bolt-6012 | M12 | 1.75 | 40 | 19 | FT | 25 | $42.19 |
| Bolt-6013 | M12 | 1.75 | 45 | 19 | FT | 25 | $47.77 |
| Bolt-6014 | M12 | 1.75 | 50 | 19 | PT | 25 | $46.89 |
| Bolt-6015 | M12 | 1.75 | 55 | 19 | PT | 10 | $21.38 |
| Bolt-6016 | M12 | 1.75 | 60 | 19 | PT | 10 | $22.61 |
| Bolt-6017 | M12 | 1.75 | 65 | 19 | PT | 5 | $12.94 |
| Bolt-6018 | M12 | 1.75 | 70 | 19 | PT | 10 | $29.52 |
| Bolt-6019 | M12 | 1.75 | 75 | 19 | PT | 5 | $18.63 |
| Bolt-6020 | M12 | 1.75 | 80 | 19 | PT | 10 | $24.66 |
| Bolt-6021 | M12 | 1.75 | 90 | 19 | PT | 10 | $31.82 |
| Bolt-6022 | M12 | 1.75 | 100 | 19 | PT | 10 | $38.36 |
| Bolt-6023 | M12 | 1.75 | 110 | 19 | PT | 5 | $23.92 |
| Bolt-6024 | M12 | 1.75 | 120 | 19 | PT | 5 | $27.56 |
| Bolt-6025 | M14 | 2 | 25 | 22 | FT | 5 | $14.92 |
| Bolt-6026 | M14 | 2 | 30 | 22 | FT | 50 | $98.77 |
| Bolt-6027 | M14 | 2 | 35 | 22 | FT | 10 | $14.92 |
| Bolt-6028 | M14 | 2 | 40 | 22 | FT | 10 | $24.75 |
| Bolt-6029 | M14 | 2 | 45 | 22 | FT | 10 | $23.74 |
| Bolt-6030 | M14 | 2 | 50 | 22 | FT | 5 | $29.57 |
| Bolt-6031 | M14 | 2 | 60 | 22 | PT | 25 | $77.85 |
| Bolt-6033 | M14 | 2 | 70 | 22 | PT | 25 | $88.02 |
| Bolt-6034 | M14 | 2 | 80 | 22 | PT | 5 | $22.79 |
| Bolt-6035 | M14 | 2 | 90 | 22 | PT | 10 | $42.75 |
| Bolt-6036 | M14 | 2 | 100 | 22 | PT | 10 | $46.69 |
| Bolt-6037 | M14 | 2 | 110 | 22 | PT | 5 | $30.42 |
| Bolt-6038 | M14 | 2 | 120 | 22 | PT | 10 | $94.23 |
| Bolt-6039 | M16 | 2 | 30 | 24 | FT | 10 | $26.37 |
| Bolt-6040 | M16 | 2 | 35 | 24 | PT | 5 | $21.53 |
| Bolt-6041 | M16 | 2 | 35 | 24 | FT | 1 | $6.08 |
| Bolt-6042 | M16 | 2 | 40 | 24 | FT | 10 | $30.98 |
| Bolt-6043 | M16 | 2 | 45 | 24 | FT | 5 | $17.82 |
| Bolt-6044 | M16 | 2 | 45 | 24 | PT | 10 | $58.50 |
| Bolt-6045 | M16 | 2 | 50 | 24 | FT | 10 | $37.76 |
| Bolt-6046 | M16 | 2 | 55 | 24 | PT | 5 | $19.76 |
| Bolt-6047 | M16 | 2 | 60 | 24 | PT | 10 | $37.94 |
| Bolt-6048 | M16 | 2 | 60 | 24 | FT | 5 | $20.75 |
| Bolt-6049 | M16 | 2 | 65 | 24 | PT | 5 | $35.84 |
| Bolt-6050 | M16 | 2 | 70 | 24 | PT | 10 | $44.26 |
| Bolt-6051 | M16 | 2 | 75 | 24 | PT | 5 | $25.13 |
| Bolt-6052 | M16 | 2 | 80 | 24 | PT | 10 | $51.82 |
| Bolt-6053 | M16 | 2 | 90 | 24 | PT | 5 | $19.44 |
| Bolt-6054 | M16 | 2 | 100 | 24 | PT | 5 | $35.17 |
| Bolt-6055 | M16 | 2 | 110 | 24 | PT | 5 | $32.92 |
| Bolt-6056 | M16 | 2 | 120 | 24 | PT | 5 | $40.93 |
| Bolt-6057 | M16 | 2 | 130 | 24 | PT | 5 | $137.72 |
| Bolt-6058 | M16 | 2 | 140 | 24 | PT | 1 | $9.58 |
| Bolt-6059 | M16 | 2 | 150 | 24 | PT | 1 | $7.49 |
| Bolt-6060 | M16 | 2 | 160 | 24 | PT | 1 | $8.01 |
| Bolt-6061 | M16 | 2 | 170 | 24 | PT | 1 | $14.00 |
| Bolt-6062 | M16 | 2 | 180 | 24 | PT | 1 | $19.85 |
| Bolt-6063 | M16 | 2 | 190 | 24 | PT | 1 | $21.89 |
| Bolt-6064 | M16 | 2 | 200 | 24 | PT | 1 | $22.61 |
| Bolt-6065 | M16 | 2 | 210 | 24 | PT | 1 | $18.70 |
| Bolt-6066 | M16 | 2 | 220 | 24 | PT | 1 | $27.63 |
| Bolt-6067 | M16 | 2 | 230 | 24 | PT | 1 | $29.86 |
| Bolt-6068 | M16 | 2 | 240 | 24 | PT | 1 | $32.27 |
| Bolt-6069 | M16 | 2 | 250 | 24 | PT | 1 | $35.06 |
| Bolt-6070 | M20 | 2.5 | 35 | 30 | FT | 1 | $6.52 |
| Bolt-6072 | M20 | 2.5 | 40 | 30 | FT | 10 | $63.23 |
| Bolt-6073 | M20 | 2.5 | 45 | 30 | FT | 1 | $6.57 |
| Bolt-6075 | M20 | 2.5 | 50 | 30 | FT | 10 | $64.19 |
| Bolt-6076 | M20 | 2.5 | 55 | 30 | PT | 5 | $52.40 |
| Bolt-6077 | M20 | 2.5 | 60 | 30 | PT | 10 | $34.34 |
| Bolt-6078 | M20 | 2.5 | 60 | 30 | FT | 10 | $72.92 |
| Bolt-6079 | M20 | 2.5 | 65 | 30 | PT | 1 | $8.82 |
| Bolt-6080 | M20 | 2.5 | 70 | 30 | FT | 10 | $74.30 |
| Bolt-6081 | M20 | 2.5 | 75 | 30 | PT | 5 | $39.94 |
| Bolt-6082 | M20 | 2.5 | 80 | 30 | PT | 10 | $63.23 |
| Bolt-6083 | M20 | 2.5 | 90 | 30 | PT | 5 | $46.10 |
| Bolt-6084 | M20 | 2.5 | 100 | 30 | PT | 5 | $56.79 |
| Bolt-6085 | M20 | 2.5 | 110 | 30 | PT | 1 | $13.14 |
| Bolt-6086 | M20 | 2.5 | 120 | 30 | PT | 3 | $37.49 |
| Bolt-6087 | M20 | 2.5 | 130 | 30 | PT | 1 | $15.73 |
| Bolt-6088 | M20 | 2.5 | 140 | 30 | PT | 3 | $42.07 |
| Bolt-6089 | M20 | 2.5 | 150 | 30 | PT | 1 | $17.30 |
| Bolt-6090 | M20 | 2.5 | 160 | 30 | PT | 1 | $12.38 |
| Bolt-6091 | M20 | 2.5 | 170 | 30 | PT | 1 | $26.96 |
| Bolt-6092 | M20 | 2.5 | 180 | 30 | PT | 1 | $27.54 |
| Bolt-6093 | M20 | 2.5 | 190 | 30 | PT | 1 | $22.03 |
| Bolt-6094 | M20 | 2.5 | 200 | 30 | PT | 3 | $72.90 |
| Bolt-6095 | M20 | 2.5 | 210 | 30 | PT | 1 | $22.50 |
| Bolt-6096 | M20 | 2.5 | 220 | 30 | PT | 1 | $24.19 |
| Bolt-6097 | M20 | 2.5 | 240 | 30 | PT | 1 | $26.66 |
| Bolt-6098 | M20 | 2.5 | 250 | 30 | PT | 1 | $29.34 |
| Bolt-6099 | M22 | 2.5 | 80 | 36 | PT | 5 | $70.11 |
| Bolt-6100 | M24 | 3 | 40 | 36 | FT | 1 | $12.69 |
| Bolt-6101 | M24 | 3 | 50 | 36 | FT | 1 | $13.93 |
| Bolt-6102 | M24 | 3 | 60 | 36 | FT | 5 | $53.84 |
| Bolt-6104 | M24 | 3 | 70 | 36 | FT | 5 | $61.65 |
| Bolt-6105 | M24 | 3 | 70 | 36 | PT | 1 | $18.00 |
| Bolt-6106 | M24 | 3 | 75 | 36 | PT | 1 | $15.46 |
| Bolt-6107 | M24 | 3 | 80 | 36 | PT | 3 | $71.69 |
| Bolt-6108 | M24 | 3 | 90 | 36 | PT | 3 | $74.09 |
| Bolt-6109 | M24 | 3 | 100 | 36 | PT | 3 | $57.87 |
| Bolt-6110 | M24 | 3 | 110 | 36 | PT | 3 | $52.45 |
| Bolt-6111 | M24 | 3 | 120 | 36 | PT | 3 | $59.92 |
| Bolt-6112 | M24 | 3 | 130 | 36 | PT | 1 | $11.21 |
| Bolt-6113 | M24 | 3 | 140 | 36 | PT | 1 | $22.10 |
| Bolt-6114 | M24 | 3 | 150 | 36 | PT | 1 | $26.73 |
| Bolt-6115 | M24 | 3 | 160 | 36 | FT | 1 | $38.88 |
| Bolt-6116 | M24 | 3 | 160 | 36 | PT | 3 | $76.01 |
| Bolt-6117 | M24 | 3 | 170 | 36 | PT | 1 | $25.25 |
| Bolt-6118 | M24 | 3 | 180 | 36 | PT | 1 | $23.96 |
| Bolt-6119 | M24 | 3 | 190 | 36 | PT | 1 | $34.38 |
| Bolt-6120 | M24 | 3 | 200 | 36 | PT | 1 | $34.13 |
| Bolt-6121 | M24 | 3 | 210 | 36 | PT | 1 | $39.74 |
| Bolt-6122 | M24 | 3 | 220 | 36 | PT | 1 | $41.15 |
| Bolt-6123 | M24 | 3 | 240 | 36 | PT | 1 | $19.17 |
| Bolt-6124 | M24 | 3 | 250 | 36 | PT | 1 | $54.56 |
| Bolt-6125 | M30 | 3.5 | 70 | 46 | PT | 5 | $106.31 |
| Bolt-6126 | M30 | 3.5 | 80 | 46 | PT | 5 | $269.93 |
| Bolt-6127 | M30 | 3.5 | 100 | 46 | PT | 3 | $126.02 |
| Bolt-6128 | M30 | 3.5 | 130 | 46 | PT | 3 | $121.55 |
| Rev. 08-26, 05-26, 11-25, 03-25 | |||||||
