Metric Class 10.9 Black Oxide Steel Flange Head Bolts
RH Threads
| Metric Class 10.9 Black Oxide Steel Flange Head Bolts Fully Threaded | ||||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Flange Diameter | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-5333 | M5 x 0.8 | 10mm | 8mm | 5.4mm | 11.8mm | 100 | $19.07 | Add to Order |
| Bolt-5334 | M5 x 0.8 | 12mm | 8mm | 5.4mm | 11.8mm | 100 | $18.00 | Add to Order |
| Bolt-5335 | M5 x 0.8 | 16mm | 8mm | 5.4mm | 11.8mm | 100 | $16.80 | Add to Order |
| Bolt-5336 | M5 x 0.8 | 20mm | 8mm | 5.4mm | 11.8mm | 100 | $28.96 | Add to Order |
| Bolt-5337 | M6 x 1 | 10mm | 10mm | 6.6mm | 14.2mm | 100 | $28.96 | Add to Order |
| Bolt-5338 | M6 x 1 | 12mm | 10mm | 6.6mm | 14.2mm | 100 | $28.98 | Add to Order |
| Bolt-5339 | M6 x 1 | 16mm | 10mm | 6.6mm | 14.2mm | 100 | $36.20 | Add to Order |
| Bolt-5340 | M6 x 1 | 20mm | 10mm | 6.6mm | 14.2mm | 100 | $36.23 | Add to Order |
| Bolt-5343 | M8 x 1.25 | 12mm | 13mm | 8.1mm | 18mm | 50 | $28.94 | Add to Order |
| Bolt-5344 | M8 x 1.25 | 16mm | 13mm | 8.1mm | 18mm | 50 | $32.59 | Add to Order |
| Bolt-5345 | M8 x 1.25 | 20mm | 13mm | 8.1mm | 18mm | 50 | $42.32 | Add to Order |
| Bolt-5346 | M8 x 1.25 | 25mm | 13mm | 8.1mm | 18mm | 50 | $44.88 | Add to Order |
| Bolt-5347 | M8 x 1.25 | 30mm | 13mm | 8.1mm | 18mm | 50 | $47.75 | Add to Order |
| Bolt-5353 | M10 x 1.5 | 16mm | 15mm | 10.4mm | 22.3mm | 50 | $54.35 | Add to Order |
| Bolt-5354 | M10 x 1.5 | 20mm | 15mm | 10.4mm | 22.3mm | 25 | $34.99 | Add to Order |
| Bolt-5355 | M10 x 1.5 | 25mm | 15mm | 10.4mm | 22.3mm | 25 | $36.31 | Add to Order |
| Bolt-5356 | M10 x 1.5 | 30mm | 15mm | 10.4mm | 22.3mm | 25 | $37.93 | Add to Order |
| Bolt-5357 | M10 x 1.5 | 35mm | 15mm | 10.4mm | 22.3mm | 25 | $38.01 | Add to Order |
| Bolt-5366 | M12 x 1.75 | 20mm | 18mm | 11.8mm | 26.6mm | 20 | $31.84 | Add to Order |
| Bolt-5367 | M12 x 1.75 | 25mm | 18mm | 11.8mm | 26.6mm | 20 | $48.85 | Add to Order |
| Bolt-5368 | M12 x 1.75 | 30mm | 18mm | 11.8mm | 26.6mm | 20 | $49.43 | Add to Order |
| Bolt-5369 | M12 x 1.75 | 35mm | 18mm | 11.8mm | 26.6mm | 20 | $51.53 | Add to Order |
| Bolt-5370 | M12 x 1.75 | 40mm | 18mm | 11.8mm | 26.6mm | 20 | $51.74 | Add to Order |
| Bolt-5378 | M14 x 2 | 35mm | 18mm | 12.8mm | 30.5mm | 10 | $34.78 | Add to Order |
| Bolt-5387 | M16 x 2 | 30mm | 24mm | 15.4mm | 35mm | 10 | $45.28 | Add to Order |
| Bolt-5388 | M16 x 2 | 35mm | 24mm | 15.4mm | 35mm | 10 | $43.13 | Add to Order |
| Bolt-5389 | M16 x 2 | 40mm | 24mm | 15.4mm | 35mm | 5 | $29.00 | Add to Order |
| Bolt-5390 | M16 x 2 | 50mm | 24mm | 15.4mm | 35mm | 5 | $24.84 | Add to Order |
| Rev. 04-23, 11-22, 08-22, 02-22 | ||||||||
| Metric Class 10.9 Black Oxide Steel Flange Head Bolts Partially Threaded | |||||||||
| Part # | Thread Length | Thread Size | Overall Length | Head Width | Head Height | Flange Diameter | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| Bolt-5341 | 18 to 23 | M6 x 1 | 25mm | 10mm | 6.6mm | 14.2mm | 100 | $28.98 | Add to Order |
| Bolt-5342 | 18 to 23 | M6 x 1 | 30mm | 10mm | 6.6mm | 14.2mm | 100 | $43.47 | Add to Order |
| Bolt-5348 | 22 to 29 | M8 x 1.25 | 35mm | 13mm | 8.1mm | 18mm | 50 | $47.84 | Add to Order |
| Bolt-5349 | 22 to 29 | M8 x 1.25 | 40mm | 13mm | 8.1mm | 18mm | 50 | $37.53 | Add to Order |
| Bolt-5350 | 22 to 29 | M8 x 1.25 | 45mm | 13mm | 8.1mm | 18mm | 25 | $31.40 | Add to Order |
| Bolt-5351 | 22 to 29 | M8 x 1.25 | 50mm | 13mm | 8.1mm | 18mm | 25 | $32.76 | Add to Order |
| Bolt-5352 | 22 to 29 | M8 x 1.25 | 60mm | 13mm | 8.1mm | 18mm | 25 | $35.83 | Add to Order |
| Bolt-5358 | 26 to 34 | M10 x 1.5 | 40mm | 15mm | 10.4mm | 22.3mm | 25 | $50.88 | Add to Order |
| Bolt-5359 | 26 to 34 | M10 x 1.5 | 45mm | 15mm | 10.4mm | 22.3mm | 20 | $40.15 | Add to Order |
| Bolt-5360 | 26 to 34 | M10 x 1.5 | 50mm | 15mm | 10.4mm | 22.3mm | 20 | $42.67 | Add to Order |
| Bolt-5361 | 26 to 34 | M10 x 1.5 | 60mm | 15mm | 10.4mm | 22.3mm | 10 | $23.79 | Add to Order |
| Bolt-5362 | 26 to 34 | M10 x 1.5 | 70mm | 15mm | 10.4mm | 22.3mm | 10 | $25.03 | Add to Order |
| Bolt-5363 | 26 to 34 | M10 x 1.5 | 80mm | 15mm | 10.4mm | 22.3mm | 10 | $27.03 | Add to Order |
| Bolt-5364 | 26 to 34 | M10 x 1.5 | 90mm | 15mm | 10.4mm | 22.3mm | 10 | $30.26 | Add to Order |
| Bolt-5365 | 26 to 34 | M10 x 1.5 | 100mm | 15mm | 10.4mm | 22.3mm | 10 | $31.29 | Add to Order |
| Bolt-5371 | 30 to 39 | M12 x 1.75 | 45mm | 18mm | 11.8mm | 26.6mm | 20 | $56.49 | Add to Order |
| Bolt-5372 | 30 to 39 | M12 x 1.75 | 50mm | 18mm | 11.8mm | 26.6mm | 10 | $36.88 | Add to Order |
| Bolt-5373 | 30 to 39 | M12 x 1.75 | 60mm | 18mm | 11.8mm | 26.6mm | 10 | $31.82 | Add to Order |
| Bolt-5374 | 30 to 39 | M12 x 1.75 | 70mm | 18mm | 11.8mm | 26.6mm | 10 | $32.91 | Add to Order |
| Bolt-5375 | 30 to 39 | M12 x 1.75 | 80mm | 18mm | 11.8mm | 26.6mm | 10 | $52.62 | Add to Order |
| Bolt-5376 | 30 to 39 | M12 x 1.75 | 90mm | 18mm | 11.8mm | 26.6mm | 5 | $21.04 | Add to Order |
| Bolt-5377 | 30 to 39 | M12 x 1.75 | 100mm | 18mm | 11.8mm | 26.6mm | 10 | $45.19 | Add to Order |
| Bolt-5379 | 34 to full | M14 x 2 | 40mm | 18mm | 12.8mm | 30.5mm | 10 | $37.30 | Add to Order |
| Bolt-5380 | 34 to full | M14 x 2 | 45mm | 18mm | 12.8mm | 30.5mm | 5 | $19.80 | Add to Order |
| Bolt-5381 | 34 to full | M14 x 2 | 50mm | 18mm | 12.8mm | 30.5mm | 5 | $23.06 | Add to Order |
| Bolt-5382 | 34 to full | M14 x 2 | 60mm | 18mm | 12.8mm | 30.5mm | 5 | $24.61 | Add to Order |
| Bolt-5383 | 34 to full | M14 x 2 | 70mm | 18mm | 12.8mm | 30.5mm | 5 | $26.80 | Add to Order |
| Bolt-5384 | 34 to full | M14 x 2 | 80mm | 18mm | 12.8mm | 30.5mm | 5 | $28.67 | Add to Order |
| Bolt-5385 | 34 to full | M14 x 2 | 90mm | 18mm | 12.8mm | 30.5mm | 5 | $33.08 | Add to Order |
| Bolt-5386 | 34 to full | M14 x 2 | 100mm | 18mm | 12.8mm | 30.5mm | 5 | $36.86 | Add to Order |
| Bolt-5391 | 38 to 48 | M16 x 2 | 60mm | 24mm | 15.4mm | 35mm | 5 | $34.67 | Add to Order |
| Bolt-5392 | 38 to 48 | M16 x 2 | 70mm | 24mm | 15.4mm | 35mm | 5 | $30.20 | Add to Order |
| Bolt-5393 | 38 to 48 | M16 x 2 | 80mm | 24mm | 15.4mm | 35mm | 5 | $35.30 | Add to Order |
| Bolt-5394 | 38 to 48 | M16 x 2 | 90mm | 24mm | 15.4mm | 35mm | 5 | $38.09 | Add to Order |
| Bolt-5395 | 38 to 48 | M16 x 2 | 100mm | 24mm | 15.4mm | 35mm | 5 | $33.60 | Add to Order |
| Rev. 04-23, 11-22, 08-22, 03-22 | |||||||||
