Nylon Bolts
RH Threads, Black & Natural
| Nylon Bolts, Full Threads | |||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| Bolt-4849 | 1/4"-20 | .375" | 7/16" | 3/16" | 100 | $53.68 | Add to Order |
| Bolt-4850 | 1/4"-20 | .500" | 7/16" | 3/16" | 100 | $30.16 | Add to Order |
| Bolt-4851 | 1/4"-20 | .750" | 7/16" | 3/16" | 100 | $55.27 | Add to Order |
| Bolt-4852 | 1/4"-20 | 1.00" | 7/16" | 3/16" | 100 | $58.99 | Add to Order |
| Bolt-4856 | 5/16"-18 | .500" | 1/2" | 15/64" | 50 | $48.95 | Add to Order |
| Bolt-4857 | 5/16"-18 | .750" | 1/2" | 15/64" | 50 | $49.67 | Add to Order |
| Bolt-4858 | 5/16"-18 | 1.00" | 1/2" | 15/64" | 50 | $50.34 | Add to Order |
| Bolt-4864 | 3/8"-16 | .500" | 9/16" | 17/64" | 50 | $45.36 | Add to Order |
| Bolt-4865 | 3/8"-16 | .750" | 9/16" | 17/64" | 50 | $46.28 | Add to Order |
| Bolt-4866 | 3/8"-16 | 1.00" | 9/16" | 17/64" | 50 | $52.46 | Add to Order |
| Bolt-4872 | 1/2"-13 | .500" | 3/4" | 23/64" | 20 | $44.60 | Add to Order |
| Bolt-4873 | 1/2"-13 | .750" | 3/4" | 23/64" | 20 | $45.91 | Add to Order |
| Bolt-4874 | 1/2"-13 | 1.00" | 3/4" | 23/64" | 20 | $47.12 | Add to Order |
| Bolt-4875 | 1/2"-13 | 1.25" | 3/4" | 23/64" | 20 | $48.30 | Add to Order |
| Bolt-4880 | 5/8"-11 | .500" | 15/16" | 7/16" | 20 | $51.74 | Add to Order |
| Bolt-4881 | 5/8"-11 | 1.00" | 15/16" | 7/16" | 20 | $54.89 | Add to Order |
| Rev. 03-25, 06-24, 04-23, 02-23 | |||||||
Nylon Bolts, Partial Threads
| Nylon Bolts, Partial Threads | ||||||||
| Part # | Thread Length | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-4867 | 1" | 3/8"-16 | 1.25" | 9/16" | 17/64" | 50 | $120.75 | Add to Order |
| Bolt-4868 | 1" | 3/8"-16 | 1.50" | 9/16" | 17/64" | 50 | $58.19 | Add to Order |
| Bolt-4869 | 1" | 3/8"-16 | 2.00" | 9/16" | 17/64" | 25 | $37.99 | Add to Order |
| Bolt-4870 | 1" | 3/8"-16 | 2.50" | 9/16" | 17/64" | 25 | $41.45 | Add to Order |
| Bolt-4871 | 1" | 3/8"-16 | 3.00" | 9/16" | 17/64" | 25 | $43.18 | Add to Order |
| Bolt-4876 | 1-1/4" | 1/2"-13 | 1.50" | 3/4" | 23/64" | 20 | $49.56 | Add to Order |
| Bolt-4877 | 1-1/4" | 1/2"-13 | 2.00" | 3/4" | 23/64" | 20 | $52.04 | Add to Order |
| Bolt-4878 | 1-1/4" | 1/2"-13 | 2.50" | 3/4" | 23/64" | 20 | $52.67 | Add to Order |
| Bolt-4879 | 1-1/4" | 1/2"-13 | 3.00" | 3/4" | 23/64" | 20 | $62.33 | Add to Order |
| Bolt-4882 | 1-1/2" | 5/8"-11 | 2.00" | 15/16" | 7/16" | 20 | $62.33 | Add to Order |
| Rev. 03-25, 04-23, 11-22, 08-22 | ||||||||
