Plastic Selections

TYGON® F-4040-A Fuel and Lubricant Tubing

Resists embrittlement
Compatible with most petroleum-based products
Resists swelling and cracking
Ozone and UV light resistant

Tygon® F-4040-A Fuel and Lubricant Tubing
A consistent performer lot after lot, Tygon® Fuel and Lubricant Tubing is the most requested fuel and lubricant tubing for a variety of applications -- from small engine fuel lines to coolant transfer. Specifically designed to handle most fuels and industrial lubricants, Tygon® Fuel and Lubricant Tubing resists the swelling and hardening caused by hydrocarbon-based fluids. This significantly reduces the risk of failure due to cracking and leakage. Its minimum extractability safeguards the liquid or vapor being transferred against adulteration.

Extremely flexible (Shore A, 57), Tygon® Fuel and Lubricant Tubing simplifies installation, even in tight places. It is translucent yellow for positive identification and to allow easy flow monitoring. It is routinely used to handle gasoline, kerosene, heating oils, cutting compounds and glycol-based coolants.

Technical Data

Order F4040-A Tygon Tubing Online-Click Here

**Denotes 2 Week lead time.

Tygon® F-4040-A Fuel and Lubricant Tubing
Tygon Part #	Outside Diameter Inches	Inside Diameter Inches	Wall Inches	Stock #	Price per Package (50 feet)	Purchase Online
AAG00700	0.140	0.080	0.030	KM-2671	$54.70	Buy Now
AAG00165	0.188	0.094	0.047	KM-2672	$54.70	Buy Now
	0.218	0.094	0.062	KM-4683W**	$60.00	Buy Now
AAG00007	0.250	0.125	0.063	KM-2673	$69.80	Buy Now
AAG00012	0.313	0.188	0.063	KM-2674	$99.90	Buy Now
AAG00017	0.375	0.250	0.063	KM-2675	$120.80	Buy Now
AAG00022	0.438	0.313	0.063	KM-2676	$145.10	Buy Now
AAG00027	0.500	0.375	0.063	KM-2677	$170.90	Buy Now
AAG00029	0.625	0.375	0.125	KM-2678	$318.10	Buy Now
AAG00032	0.563	0.438	0.125	KM-2679	$201.30	Buy Now
AAG00036	0.625	0.500	0.063	KM-2680	$206.70	Buy Now
AAG00038	0.750	0.500	0.125	KM-2681	$383.20	Buy Now
AAG00046	0.875	0.625	0.125	KM-5179	$424.80	Buy Now
AAG00053	1.000	0.750	0.125	KM-2683	$493.20	Buy Now
