PTFE Micro Tubing
Virgin PTFE Tubing is the best chemically resistant material available and it continuously handles high temperatures.
PTFE
Typical Properties
PTFE
Chemical Resistance
Click Here for Larger PTFE Extruded Tubing
Click Here for Molded PTFE Tubes
| PTFE Micro Tubing | ||||||
| 1 Week Lead Time on AWG Sizes | ||||||
| Part # | OD (in.) | ID (in.) | Wall Thickness (in.) | Price Per 100 Feet | Size | Order Online |
|---|---|---|---|---|---|---|
| KM-23922 | 0.014 | 0.002 | 0.006 | $708.75 | - | Add to Order |
| KM-23148 | 0.033 | 0.015 | 0.009 | $42.75 | 28 | Add to Order |
| KM-23145 | 0.030 | 0.018 | 0.006 | $24.27 | 26 | Add to Order |
| KM-23146 | 0.036 | 0.018 | 0.009 | $26.97 | 26 | Add to Order |
| KM-23139 | 0.034 | 0.022 | 0.006 | $25.92 | 24 | Add to Order |
| KM-23140 | 0.042 | 0.022 | 0.010 | $42.75 | 24 | Add to Order |
| KM-23143 | 0.046 | 0.022 | 0.012 | $35.31 | 24 | Add to Order |
| KM-23135 | 0.054 | 0.022 | 0.016 | $54.09 | 24 | Add to Order |
| KM-23158 | 0.038 | 0.026 | 0.006 | $26.55 | 23 | Add to Order |
| KM-23157 | 0.046 | 0.026 | 0.010 | $33.09 | 23 | Add to Order |
| KM-23162 | 0.040 | 0.028 | 0.006 | $29.04 | 22 | Add to Order |
| KM-23160 | 0.052 | 0.028 | 0.016 | $42.15 | 22 | Add to Order |
| KM-23166 | 0.044 | 0.032 | 0.006 | $30.42 | 21 | Add to Order |
| KM-23164 | 0.056 | 0.032 | 0.012 | $116.77 | 21 | Add to Order |
| KM-23170 | 0.058 | 0.034 | 0.012 | $67.50 | 20 | Add to Order |
| KM-23136 | 0.062 | 0.038 | 0.012 | $74.25 | 19 | Add to Order |
| KM-23151 | 0.054 | 0.042 | 0.006 | $37.11 | 18 | Add to Order |
| KM-23141 | 0.082 | 0.042 | 0.020 | $96.21 | 18 | Add to Order |
| KM-23191 | 0.060 | 0.048 | 0.006 | $42.51 | 17 | Add to Order |
| KM-23194 | 0.072 | 0.048 | 0.012 | $85.50 | 17 | Add to Order |
| KM-23195 | 0.077 | 0.053 | 0.012 | $92.25 | 16 | Add to Order |
| KM-23203 | 0.071 | 0.059 | 0.006 | $49.41 | 15 | Add to Order |
| KM-23204 | 0.082 | 0.066 | 0.008 | $51.87 | 14 | Add to Order |
| KM-23207 | 0.090 | 0.066 | 0.012 | $105.75 | 14 | Add to Order |
| KM-23201 | 0.100 | 0.076 | 0.012 | $121.50 | 13 | Add to Order |
| KM-23200 | 0.116 | 0.076 | 0.020 | $151.77 | 13 | Add to Order |
| KM-23189 | 0.119 | 0.095 | 0.012 | $148.50 | 11 | Add to Order |
| KM-23178 | 0.127 | 0.095 | 0.016 | $141.63 | 11 | Add to Order |
| KM-23182 | 0.122 | 0.106 | 0.008 | $80.10 | 10 | Add to Order |
| KM-23193 | 0.130 | 0.106 | 0.012 | $224.00 | 10 | Add to Order |
| KM-23073 | 0.165 | 0.125 | 0.020 | $201.54 | 1/8 | Add to Order |
| KM-23075 | 0.163 | 0.133 | 0.015 | $256.50 | 8 | Add to Order |
| KM-23083 | 0.196 | 0.166 | 0.015 | $310.50 | 6 | Add to Order |
| KM-23115 | 0.238 | 0.208 | 0.015 | $384.75 | 4 | Add to Order |
| KM-23070 | 0.275 | 0.255 | 0.010 | $245.13 | 1/4 | Add to Order |
| Rev. 03-24, 10-23, 04-23, 03-22 | ||||||
