17-4PH Stainless Steel Rods



Technical Data



17-4PH Stainless Steel Rods

Precision Ground Finish

Tight-Tolerance Undersize Rods-Precision Ground Finish. Annealed. ASTM A564.

Type 17-4 is a martensitic precipitation hardening (maraging) steel that combines high strength and hardness with excellent corrosion resistance. A simple one-step aging treatment in the range of 900 to 1150� hardens the alloy to its design strength levels.

Also known as type 630, it can be precipitation hardened by a low cost treatment. 630 is magnetic in both the solution annealed and precipitation hardened conditions.

Straightness Tolerance .001"/Foot.  Diameter Tolerance -.0005", Length tolerance +/- 1/32"

Stock # Diameter Length  Price Each  Purchase Online
MR-5876 .125" 12" $20.76 Buy Now
MR-5890 .125" 36" $51.93 Buy Now
MR-5904 .125" 72" $86.55 Buy Now
MR-5877 .1562" 12" $23.67 Buy Now
MR-5891 .1562" 36" $59.22 Buy Now
MR-5905 .1562" 72" $98.70 Buy Now
MR-5878 .1875" 12" $28.23 Buy Now
MR-5892 .1875" 36" $70.56 Buy Now
MR-5906 .1875" 72" $117.60 Buy Now
MR-5879 .250" 12" $29.61 Buy Now
MR-5893 .250" 36" $72.45 Buy Now
MR-5907 .250" 72" $121.98 Buy Now
MR-5880 .3125" 12" $30.24 Buy Now
MR-5894 .3125" 36" $75.63 Buy Now
MR-5908 .3125" 72" $126.06 Buy Now
MR-5881 .375" 12" $33.66 Buy Now
MR-5895 .375" 36" $84.18 Buy Now
MR-5909 .375" 72" $140.28 Buy Now
MR-5882 .4375" 12" $38.64 Buy Now
MR-5896 .4375" 36" $93.00 Buy Now
MR-5910 .4375" 72" $163.41 Buy Now
MR-5883 .500" 12" $47.49 Buy Now
MR-5897 .500" 36" $96.27 Buy Now
MR-5911 .500" 72" $170.16 Buy Now
MR-5884 .625" 12" $55.47 Buy Now
MR-5898 .625" 36" $116.19 Buy Now
MR-5912 .625" 72" $206.04 Buy Now
MR-5885 .750" 12" $66.15 Buy Now
MR-5899 .750" 36" $135.36 Buy Now
MR-5913 .750" 72" $266.46 Buy Now
MR-5886 .875" 12" $76.89 Buy Now
MR-5900 .875" 36" $176.82 Buy Now
MR-5914 .875" 72" $307.53 Buy Now
MR-5887 1.00" 12" $97.89 Buy Now
MR-5901 1.00" 36" $225.15 Buy Now
MR-5915 1.00" 72" $391.56 Buy Now
MR-5888 1.25" 12" $141.39 Buy Now
MR-5902 1.25" 36" $325.20 Buy Now
MR-5916 1.25" 72" $565.56 Buy Now
MR-5889 1.50" 12" $172.62 Buy Now
MR-5903 1.50" 36" $397.02 Buy Now
MR-5917 1.50" 72" $690.45 Buy Now









Prices are subject to change due to fluctuating market conditions.
