Stainless Steel Nylon Tip Set Screws
| Stainless Steel Nylon Tip Set Screws, Rockwell B80, ASME B18.3, -50° to 250° |
||||||||
Thread Length:  |
Tip Length: |
Tip Diameter: |
||||||
| Part # | Threads | Thread Length | Tip Diameter | Tip Length | Drive Size | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| SSS-9003 | 0-80 | 3/32" | 0.031" | 0.031" | 0.028" | 1 | $5.30 | Add to Order |
| SSS-9004 | 0-80 | 1/8" | 0.031" | 0.031" | 0.028" | 1 | $12.71 | Add to Order |
| SSS-9005 | 0-80 | 3/16" | 0.031" | 0.031" | 0.028" | 1 | $12.56 | Add to Order |
| SSS-9006 | 1-72 | 3/32" | 0.031" | 0.031" | 0.035" | 1 | $12.77 | Add to Order |
| SSS-9007 | 1-72 | 1/8" | 0.031" | 0.031" | 0.035" | 1 | $12.54 | Add to Order |
| SSS-9008 | 1-72 | 3/16" | 0.031" | 0.031" | 0.035" | 1 | $12.43 | Add to Order |
| SSS-2252 | 2-56 | 1/8" | 0.031" | 0.031" | 0.035" | 10 | $12.38 | Add to Order |
| SSS-9009 | 2-56 | 3/16" | 0.031" | 0.031" | 0.035" | 10 | $26.40 | Add to Order |
| SSS-2253 | 2-56 | 1/4" | 0.031" | 0.031" | 0.035" | 10 | $12.15 | Add to Order |
| SSS-2254 | 4-40 | 1/8" | 0.063" | 0.031" | 0.050" | 10 | $8.25 | Add to Order |
| SSS-2255 | 4-40 | 3/16" | 0.063" | 0.031" | 0.050" | 10 | $8.00 | Add to Order |
| SSS-2256 | 4-40 | 1/4" | 0.063" | 0.031" | 0.050" | 10 | $10.08 | Add to Order |
| SSS-9001 | 4-40 | 5/16" | 0.063" | 0.031" | 0.050" | 10 | $9.60 | Add to Order |
| SSS-2257 | 4-40 | 3/8" | 0.063" | 0.031" | 0.050" | 10 | $7.20 | Add to Order |
| SSS-9002 | 4-40 | 1/2" | 0.063" | 0.031" | 0.050" | 10 | $10.45 | Add to Order |
| SSS-2258 | 6-32 | 1/8" | 0.063" | 0.031" | 1/16" | 10 | $7.75 | Add to Order |
| SSS-2259 | 6-32 | 3/16" | 0.063" | 0.031" | 1/16" | 10 | $9.10 | Add to Order |
| SSS-2260 | 6-32 | 1/4" | 0.063" | 0.031" | 1/16" | 10 | $10.40 | Add to Order |
| SSS-9011 | 6-32 | 5/16" | 0.063" | 0.031" | 1/16" | 10 | $30.26 | Add to Order |
| SSS-2261 | 6-32 | 3/8" | 0.063" | 0.031" | 1/16" | 10 | $14.30 | Add to Order |
| SSS-2262 | 6-32 | 1/2" | 0.063" | 0.031" | 1/16" | 10 | $12.15 | Add to Order |
| SSS-2263 | 8-32 | 1/8" | 0.094" | 0.047" | 5/64" | 10 | $12.60 | Add to Order |
| SSS-2264 | 8-32 | 3/16" | 0.094" | 0.047" | 5/64" | 10 | $7.00 | Add to Order |
| SSS-2265 | 8-32 | 1/4" | 0.094" | 0.047" | 5/64" | 10 | $7.00 | Add to Order |
| SSS-9060 | 8-32 | 5/16" | 0.094" | 0.047" | 5/64" | 10 | $12.60 | Add to Order |
| SSS-2266 | 8-32 | 3/8" | 0.094" | 0.047" | 5/64" | 10 | $6.38 | Add to Order |
| SSS-9013 | 8-32 | 1/2" | 0.094" | 0.047" | 5/64" | 10 | $10.50 | Add to Order |
| SSS-2267 | 8-32 | 5/8" | 0.094" | 0.047" | 5/64" | 10 | $12.00 | Add to Order |
| SSS-2268 | 10-24 | 3/16" | 0.094" | 0.047" | 3/32" | 10 | $9.80 | Add to Order |
| SSS-2269 | 10-24 | 1/4" | 0.094" | 0.047" | 3/32" | 10 | $10.15 | Add to Order |
| SSS-2270 | 10-24 | 3/8" | 0.094" | 0.047" | 3/32" | 10 | $10.50 | Add to Order |
| SSS-9014 | 10-24 | 1/2" | 0.094" | 0.047" | 3/32" | 10 | $10.80 | Add to Order |
| SSS-2271 | 10-24 | 3/4" | 0.094" | 0.047" | 3/32" | 10 | $12.16 | Add to Order |
| SSS-2272 | 10-32 | 3/16" | 0.094" | 0.047" | 3/32" | 10 | $8.70 | Add to Order |
| SSS-2273 | 10-32 | 1/4" | 0.094" | 0.047" | 3/32" | 10 | $7.25 | Add to Order |
| SSS-9015 | 10-32 | 5/16" | 0.094" | 0.047" | 3/32" | 10 | $7.98 | Add to Order |
| SSS-2274 | 10-32 | 3/8" | 0.094" | 0.047" | 3/32" | 10 | $8.70 | Add to Order |
| SSS-2275 | 10-32 | 1/2" | 0.094" | 0.047" | 3/32" | 10 | $9.42 | Add to Order |
| SSS-9016 | 10-32 | 5/8" | 0.094" | 0.047" | 3/32" | 10 | $11.63 | Add to Order |
| SSS-2276 | 10-32 | 3/4" | 0.094" | 0.047" | 3/32" | 10 | $12.56 | Add to Order |
| SSS-2277 | 1/4"-20 | 3/16" | 0.125" | 0.063" | 1/8" | 10 | $13.50 | Add to Order |
| SSS-2278 | 1/4"-20 | 1/4" | 0.125" | 0.063" | 1/8" | 10 | $9.00 | Add to Order |
| SSS-2279 | 1/4"-20 | 5/16" | 0.125" | 0.063" | 1/8" | 10 | $9.75 | Add to Order |
| SSS-2280 | 1/4"-20 | 3/8" | 0.125" | 0.063" | 1/8" | 10 | $9.90 | Add to Order |
| SSS-2281 | 1/4"-20 | 1/2" | 0.125" | 0.063" | 1/8" | 10 | $8.25 | Add to Order |
| SSS-9017 | 1/4"-20 | 5/8" | 0.125" | 0.063" | 1/8" | 10 | $11.05 | Add to Order |
| SSS-2282 | 1/4"-20 | 3/4" | 0.125" | 0.063" | 1/8" | 10 | $11.40 | Add to Order |
| SSS-2283 | 1/4"-20 | 1" | 0.125" | 0.063" | 1/8" | 10 | $12.00 | Add to Order |
| SSS-9018 | 1/4"-28 | 3/16" | 0.125" | 0.063" | 1/8" | 10 | $29.44 | Add to Order |
| SSS-2284 | 1/4"-28 | 1/4" | 0.125" | 0.063" | 1/8" | 10 | $10.46 | Add to Order |
| SSS-9025 | 1/4"-28 | 5/16" | 0.125" | 0.063" | 1/8" | 10 | $9.30 | Add to Order |
| SSS-2285 | 1/4"-28 | 3/8" | 0.125" | 0.063" | 1/8" | 10 | $10.51 | Add to Order |
| SSS-9019 | 1/4"-28 | 1/2" | 0.125" | 0.063" | 1/8" | 10 | $12.40 | Add to Order |
| SSS-9020 | 1/4"-28 | 5/8" | 0.125" | 0.063" | 1/8" | 10 | $11.20 | Add to Order |
| SSS-9021 | 1/4"-28 | 3/4" | 0.125" | 0.063" | 1/8" | 10 | $13.65 | Add to Order |
| SSS-9080 | 1/4"-28 | 1" | 0.125" | 0.063" | 1/8" | 10 | $13.48 | Add to Order |
| SSS-9022 | 5/16"-18 | 1/4" | 0.188" | 0.094" | 5/32" | 10 | $16.80 | Add to Order |
| SSS-9023 | 5/16"-18 | 5/16" | 0.188" | 0.094" | 5/32" | 10 | $15.54 | Add to Order |
| SSS-2286 | 5/16"-18 | 3/8" | 0.188" | 0.094" | 5/32" | 10 | $10.08 | Add to Order |
| SSS-2287 | 5/16"-18 | 1/2" | 0.188" | 0.094" | 5/32" | 10 | $11.10 | Add to Order |
| SSS-2288 | 5/16"-18 | 3/4" | 0.188" | 0.094" | 5/32" | 10 | $16.80 | Add to Order |
| SSS-2289 | 5/16"-18 | 1" | 0.188" | 0.094" | 5/32" | 5 | $10.88 | Add to Order |
| SSS-9027 | 5/16"-24 | 1/4" | 0.188" | 0.094" | 5/32" | 10 | $16.63 | Add to Order |
| SSS-9024 | 5/16"-24 | 5/16" | 0.188" | 0.094" | 5/32" | 10 | $34.50 | Add to Order |
| SSS-2290 | 5/16"-24 | 3/8" | 0.188" | 0.094" | 5/32" | 10 | $12.25 | Add to Order |
| SSS-2291 | 5/16"-24 | 1/2" | 0.188" | 0.094" | 5/32" | 10 | $12.60 | Add to Order |
| SSS-9028 | 5/16"-24 | 3/4" | 0.188" | 0.094" | 5/32" | 5 | $9.26 | Add to Order |
| SSS-9029 | 5/16"-24 | 1" | 0.188" | 0.094" | 5/32" | 5 | $28.20 | Add to Order |
| SSS-9030 | 3/8"-16 | 1/4" | 0.188" | 0.094" | 3/16" | 5 | $12.00 | Add to Order |
| SSS-9031 | 3/8"-16 | 5/16" | 0.188" | 0.094" | 3/16" | 5 | $11.44 | Add to Order |
| SSS-2293 | 3/8"-16 | 3/8" | 0.188" | 0.094" | 3/16" | 10 | $15.30 | Add to Order |
| SSS-2294 | 3/8"-16 | 1/2" | 0.188" | 0.094" | 3/16" | 5 | $10.02 | Add to Order |
| SSS-9032 | 3/8"-16 | 5/8" | 0.188" | 0.094" | 3/16" | 5 | $11.00 | Add to Order |
| SSS-2295 | 3/8"-16 | 3/4" | 0.188" | 0.094" | 3/16" | 5 | $8.75 | Add to Order |
| SSS-2296 | 3/8"-16 | 1" | 0.188" | 0.094" | 3/16" | 5 | $12.00 | Add to Order |
| SSS-9033 | 3/8"-24 | 1/4" | 0.188" | 0.094" | 3/16" | 5 | $12.00 | Add to Order |
| SSS-9034 | 3/8"-24 | 5/16" | 0.188" | 0.094" | 3/16" | 5 | $11.04 | Add to Order |
| SSS-2297 | 3/8"-24 | 3/8" | 0.188" | 0.094" | 3/16" | 10 | $16.10 | Add to Order |
| SSS-9035 | 3/8"-24 | 1/2" | 0.188" | 0.094" | 3/16" | 5 | $11.25 | Add to Order |
| SSS-2298 | 3/8"-24 | 3/4" | 0.188" | 0.094" | 3/16" | 5 | $10.50 | Add to Order |
| SSS-9036 | 3/8"-24 | 1" | 0.188" | 0.094" | 3/16" | 5 | $13.31 | Add to Order |
| SSS-9037 | 1/2"-13 | 3/8" | 0.25" | 0.125" | 1/4" | 1 | $5.20 | Add to Order |
| SSS-2299 | 1/2"-13 | 5/8" | 0.25" | 0.125" | 1/4" | 5 | $13.20 | Add to Order |
| SSS-9038 | 1/2"-13 | 1/2" | 0.25" | 0.125" | 1/4" | 1 | $5.59 | Add to Order |
| SSS-2300 | 1/2"-13 | 3/4" | 0.25" | 0.125" | 1/4" | 1 | $3.30 | Add to Order |
| SSS-2301 | 1/2"-13 | 1" | 0.25" | 0.125" | 1/4" | 1 | $4.50 | Add to Order |
| SSS-9039 | 1/2"-20 | 3/8" | 0.25" | 0.125" | 1/4" | 1 | $6.11 | Add to Order |
| SSS-9041 | 1/2"-20 | 1/2" | 0.25" | 0.125" | 1/4" | 1 | $5.75 | Add to Order |
| SSS-9042 | 1/2"-20 | 5/8" | 0.25" | 0.125" | 1/4" | 1 | $5.51 | Add to Order |
| SSS-9043 | 1/2"-20 | 3/4" | 0.25" | 0.125" | 1/4" | 1 | $5.44 | Add to Order |
| SSS-9044 | 1/2"-20 | 1" | 0.25" | 0.125" | 1/4" | 1 | $5.60 | Add to Order |
| Rev. 04-23, 01-23, 12-22, 11-22 | ||||||||
