Metric Stainless Steel Nylon Tip Set Screws

Stainless Steel Nylon Tip Set Screws

Stainless Steel Nylon Tip Metric Set Screws,
Rockwell B80, ASME B18.3, -50° to 250°
Thread Length:
 Tip Length:
 Tip Diameter:
Part # Threads Pitch Thread Length Tip Diameter Tip Length Drive Size Pkg. Qty Pkg. Price Order Online
SSS-2303 M2 0.4 mm 3 mm 0.8 mm 0.8 mm 0.9 mm 1 $4.80 Add to Order
SSS-2303B M2 0.4 mm 4 mm 0.8 mm 0.8 mm 0.9 mm 1 $12.12 Add to Order
SSS-2304 M2 0.4 mm 5 mm 0.8 mm 0.8 mm 0.9 mm 1 $4.92 Add to Order
SSS-2305 M2 0.4 mm 6 mm 0.8 mm 0.8 mm 0.9 mm 1 $5.40 Add to Order
SSS-2306 M3 0.5 mm 3 mm 1.6 mm 0.8 mm 1.5 mm 5 $12.60 Add to Order
SSS-2307 M3 0.5 mm 4 mm 1.6 mm 0.8 mm 1.5 mm 5 $9.60 Add to Order
SSS-2308 M3 0.5 mm 5 mm 1.6 mm 0.8 mm 1.5 mm 5 $12.60 Add to Order
SSS-2309 M3 0.5 mm 6 mm 1.6 mm 0.8 mm 1.5 mm 5 $12.90 Add to Order
SSS-2310 M3 0.5 mm 8 mm 1.6 mm 0.8 mm 1.5 mm 1 $2.73 Add to Order
SSS-2311 M3 0.5 mm 10 mm 1.6 mm 0.8 mm 1.5 mm 1 $2.74 Add to Order
SSS-2312 M4 0.7 mm 4 mm 2.4 mm 1.2 mm 2 mm 5 $9.75 Add to Order
SSS-2313 M4 0.7 mm 5 mm 2.4 mm 1.2 mm 2 mm 5 $11.48 Add to Order
SSS-2314 M4 0.7 mm 6 mm 2.4 mm 1.2 mm 2 mm 5 $13.00 Add to Order
SSS-9090 M4 0.7 mm 8 mm 2.4 mm 1.2 mm 2 mm 5 $13.65 Add to Order
SSS-2315 M4 0.7 mm 10 mm 2.4 mm 1.2 mm 2 mm 5 $13.72 Add to Order
SSS-9091 M5 0.7 mm 5 mm 2.4 mm 1.2 mm 2.5 mm 5 $13.30 Add to Order
SSS-2316 M5 0.8 mm 6 mm 2.4 mm 1.2 mm 2.5 mm 5 $14.00 Add to Order
SSS-2317 M5 0.8 mm 8 mm 2.4 mm 1.2 mm 2.5 mm 5 $12.83 Add to Order
SSS-2318 M5 0.8 mm 10 mm 2.4 mm 1.2 mm 2.5 mm 5 $13.50 Add to Order
SSS-2319 M5 0.8 mm 14 mm 2.4 mm 1.2 mm 2.5 mm 1 $2.66 Add to Order
SSS-2320 M5 0.8 mm 20 mm 2.4 mm 1.2 mm 2.5 mm 1 $3.06 Add to Order
SSS-2321 M6 1 mm 6 mm 3.2 mm 1.6 mm 3 mm 5 $11.25 Add to Order
SSS-9092 M6 1 mm 8 mm 3.2 mm 1.6 mm 3 mm 5 $13.50 Add to Order
SSS-2322 M6 1 mm 10 mm 3.2 mm 1.6 mm 3 mm 5 $14.73 Add to Order
SSS-9093 M6 1 mm 12 mm 3.2 mm 1.6 mm 3 mm 1 $3.04 Add to Order
SSS-2323 M6 1 mm 16 mm 3.2 mm 1.6 mm 3 mm 1 $3.23 Add to Order
SSS-9045 M6 1 mm 20 mm 3.2 mm 1.6 mm 3 mm 1 $4.80 Add to Order
SSS-2324 M6 1 mm 25 mm 3.2 mm 1.6 mm 3 mm 1 $2.88 Add to Order
SSS-2325 M8 1.25 mm 6 mm 4.8 mm 2.4 mm 4 mm 1 $4.96 Add to Order
SSS-2326 M8 1.25 mm 8 mm 4.8 mm 2.4 mm 4 mm 1 $3.36 Add to Order
SSS-2327 M8 1.25 mm 10 mm 4.8 mm 2.4 mm 4 mm 1 $3.47 Add to Order
SSS-2328 M8 1.25 mm 12 mm 4.8 mm 2.4 mm 4 mm 1 $3.57 Add to Order
SSS-9094 M8 1.25 mm 25 mm 4.8 mm 2.4 mm 4 mm 1 $5.75 Add to Order
SSS-9095 M8 1.25 mm 30 mm 4.8 mm 2.4 mm 4 mm 1 $6.48 Add to Order
SSS-9096 M10 1.5 mm 12 mm 4.8 mm 2.4 mm 5 mm 1 $5.22 Add to Order
SSS-9048 M10 1.5 mm 20 mm 4.8 mm 2.4 mm 5 mm 1 $6.72 Add to Order
Rev. 10-23, 04-23, 12-22, 11-22
<<
