18-8 Stainless Steel Extended Tip Half Dog Set Screws
| 18-8 Stainless Steel Extended Tip Set Screws, Rockwell B80, ASME B18.3 |
||||||||
| Part # | Threads | Length | Tip Dia. | Tip Length | Drive Size | Pkg Qty | Pkg Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| SSS-2677 | 3-56 | 1/8" | 0.066" | 0.027" | 0.050" | 25 | $23.90 | Add to Order |
| SSS-2180 | 4-40 | 1/8" | 0.075" | 0.03" | 0.050" | 50 | $28.48 | Add to Order |
| SSS-2181 | 4-40 | 3/16" | 0.075" | 0.03" | 0.050" | 50 | $31.92 | Add to Order |
| SSS-2678 | 4-40 | 1/4" | 0.075" | 0.03" | 0.050" | 25 | $20.12 | Add to Order |
| SSS-2679 | 4-40 | 3/8" | 0.075" | 0.03" | 0.050" | 25 | $20.71 | Add to Order |
| SSS-2182 | 6-32 | 3/16" | 0.092" | 0.038" | 1/16" | 50 | $31.44 | Add to Order |
| SSS-2183 | 6-32 | 1/4" | 0.092" | 0.038" | 1/16" | 50 | $32.82 | Add to Order |
| SSS-2184 | 6-32 | 5/16" | 0.092" | 0.038" | 1/16" | 50 | $33.24 | Add to Order |
| SSS-2185 | 6-32 | 3/8" | 0.092" | 0.038" | 1/16" | 25 | $16.53 | Add to Order |
| SSS-2186 | 6-32 | 1/2" | 0.092" | 0.038" | 1/16" | 25 | $21.21 | Add to Order |
| SSS-2680 | 6-32 | 5/8" | 0.092" | 0.038" | 1/16" | 25 | $24.00 | Add to Order |
| SSS-2681 | 8-32 | 1/8" | 0.109" | 0.043" | 5/64" | 25 | $21.92 | Add to Order |
| SSS-2187 | 8-32 | 3/16" | 0.109" | 0.043" | 5/64" | 25 | $18.90 | Add to Order |
| SSS-2188 | 8-32 | 1/4" | 0.109" | 0.043" | 5/64" | 25 | $14.32 | Add to Order |
| SSS-2682B | 8-32 | 5/16" | 0.109" | 0.043" | 5/64" | 25 | $21.86 | Add to Order |
| SSS-2189 | 8-32 | 3/8" | 0.109" | 0.043" | 5/64" | 25 | $15.12 | Add to Order |
| SSS-2190 | 8-32 | 1/2" | 0.109" | 0.043" | 5/64" | 25 | $24.59 | Add to Order |
| SSS-2191 | 10-24 | 1/4" | 0.127" | 0.049" | 3/32" | 25 | $15.33 | Add to Order |
| SSS-2683 | 10-24 | 5/16" | 0.127" | 0.049" | 3/32" | 25 | $24.36 | Add to Order |
| SSS-2192 | 10-24 | 3/8" | 0.127" | 0.049" | 3/32" | 25 | $16.17 | Add to Order |
| SSS-2193 | 10-24 | 1/2" | 0.127" | 0.049" | 3/32" | 25 | $27.26 | Add to Order |
| SSS-2684 | 10-24 | 3/4" | 0.127" | 0.049" | 3/32" | 25 | $27.22 | Add to Order |
| SSS-2194 | 10-32 | 3/16" | 0.127" | 0.049" | 3/32" | 50 | $26.46 | Add to Order |
| SSS-2195 | 10-32 | 1/4" | 0.127" | 0.049" | 3/32" | 25 | $16.95 | Add to Order |
| SSS-2685 | 10-32 | 5/16" | 0.127" | 0.049" | 3/32" | 25 | $24.61 | Add to Order |
| SSS-2686 | 10-32 | 3/8" | 0.127" | 0.049" | 3/32" | 25 | $11.95 | Add to Order |
| SSS-2197 | 1/4"-20 | 1/4" | 0.156" | 0.067" | 1/8" | 25 | $26.00 | Add to Order |
| SSS-2198 | 1/4"-20 | 5/16" | 0.156" | 0.067" | 1/8" | 25 | $27.05 | Add to Order |
| SSS-2199 | 1/4"-20 | 3/8" | 0.156" | 0.067" | 1/8" | 10 | $11.89 | Add to Order |
| SSS-2200 | 1/4"-20 | 1/2" | 0.156" | 0.067" | 1/8" | 10 | $12.47 | Add to Order |
| SSS-2201 | 1/4"-20 | 5/8" | 0.156" | 0.067" | 1/8" | 10 | $15.62 | Add to Order |
| SSS-2202 | 1/4"-20 | 3/4" | 0.156" | 0.067" | 1/8" | 10 | $17.47 | Add to Order |
| SSS-2203 | 1/4"-20 | 1" | 0.156" | 0.067" | 1/8" | 10 | $21.67 | Add to Order |
| SSS-2687 | 1/4"-28 | 1/4" | 0.156" | 0.067" | 1/8" | 10 | $18.77 | Add to Order |
| SSS-2688 | 1/4"-28 | 3/8" | 0.156" | 0.067" | 1/8" | 10 | $20.22 | Add to Order |
| SSS-2204 | 5/16"-18 | 5/16" | 0.203" | 0.082" | 5/32" | 10 | $12.96 | Add to Order |
| SSS-2205 | 5/16"-18 | 3/8" | 0.203" | 0.082" | 5/32" | 10 | $13.80 | Add to Order |
| SSS-2206 | 5/16"-18 | 1/2" | 0.203" | 0.082" | 5/32" | 10 | $15.48 | Add to Order |
| SSS-12217 | 5/16"-18 | 3/4" | 0.203" | 0.082" | 5/32" | 10 | $20.48 | Add to Order |
| SSS-2208 | 5/16"-18 | 1" | 0.203" | 0.082" | 5/32" | 10 | $22.47 | Add to Order |
| SSS-2689 | 3/8"-16 | 3/8" | 0.25" | 0.099" | 3/16" | 10 | $19.66 | Add to Order |
| SSS-2209 | 3/8"-16 | 1/2" | 0.25" | 0.099" | 3/16" | 10 | $20.10 | Add to Order |
| SSS-2690 | 3/8"-16 | 5/8" | 0.25" | 0.099" | 3/16" | 10 | $22.03 | Add to Order |
| SSS-2210 | 3/8"-16 | 3/4" | 0.25" | 0.099" | 3/16" | 5 | $13.57 | Add to Order |
| SSS-2211 | 3/8"-16 | 1" | 0.25" | 0.099" | 3/16" | 5 | $14.51 | Add to Order |
| SSS-2691 | 3/8"-24 | 3/8" | 0.25" | 0.099" | 3/16" | 10 | $20.06 | Add to Order |
| SSS-2692 | 3/8"-24 | 1" | 0.25" | 0.099" | 3/16" | 5 | $33.87 | Add to Order |
| Rev. 04-23, 11-22, 03-22 | ||||||||
