Stainless Steel Brass Tip Set Screws
| Stainless Steel Brass Tip Set Screws | ||||||||
Thread Length:  |
Tip Length: |
Tip Diameter: |
||||||
| Part # | Threads | Thread Length | Tip Diameter | Tip Length | Drive Size | Pkg Qty | Pkg Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| SSS-2227 | 2-56 | 1/8" | 0.031" | 0.031" | 0.035" | 10 | $17.25 | Add to Order |
| SSS-2228 | 2-56 | 1/4" | 0.031" | 0.031" | 0.035" | 10 | $25.37 | Add to Order |
| SSS-2229 | 4-40 | 1/8" | 0.063" | 0.031" | 0.050" | 10 | $12.40 | Add to Order |
| SSS-2230 | 4-40 | 1/4" | 0.063" | 0.031" | 0.050" | 10 | $10.38 | Add to Order |
| SSS-2231 | 6-32 | 1/8" | 0.063" | 0.031" | 1/16" | 10 | $6.40 | Add to Order |
| SSS-2232 | 6-32 | 1/4" | 0.063" | 0.031" | 1/16" | 10 | $10.80 | Add to Order |
| SSS-2233 | 8-32 | 3/16" | 0.094" | 0.047" | 5/64" | 10 | $10.15 | Add to Order |
| SSS-2234 | 8-32 | 1/4" | 0.094" | 0.047" | 5/64" | 10 | $10.22 | Add to Order |
| SSS-2235 | 8-32 | 3/8" | 0.094" | 0.047" | 5/64" | 10 | $11.63 | Add to Order |
| SSS-2236 | 10-24 | 1/4" | 0.094" | 0.047" | 3/32" | 10 | $10.15 | Add to Order |
| SSS-2237 | 10-24 | 3/8" | 0.094" | 0.047" | 3/32" | 10 | $11.60 | Add to Order |
| SSS-2238 | 10-32 | 3/16" | 0.094" | 0.047" | 3/32" | 10 | $16.78 | Add to Order |
| SSS-2239 | 10-32 | 1/4" | 0.094" | 0.047" | 3/32" | 10 | $15.39 | Add to Order |
| SSS-2240 | 10-32 | 3/8" | 0.094" | 0.047" | 3/32" | 10 | $17.20 | Add to Order |
| SSS-2241 | 10-32 | 1/2" | 0.094" | 0.047" | 3/32" | 10 | $35.72 | Add to Order |
| SSS-2242 | 10-32 | 3/4" | 0.094" | 0.047" | 3/32" | 10 | $38.41 | Add to Order |
| SSS-2243 | 1/4"-20 | 1/4" | 0.125" | 0.063" | 1/8" | 10 | $15.46 | Add to Order |
| SSS-2244 | 1/4"-20 | 3/8" | 0.125" | 0.063" | 1/8" | 10 | $14.47 | Add to Order |
| SSS-2245 | 1/4"-20 | 1/2" | 0.125" | 0.063" | 1/8" | 10 | $16.53 | Add to Order |
| SSS-2246 | 1/4"-20 | 3/4" | 0.125" | 0.063" | 1/8" | 10 | $10.73 | Add to Order |
| SSS-2247 | 1/4"-28 | 1/4" | 0.125" | 0.063" | 1/8" | 10 | $17.07 | Add to Order |
| SSS-2248 | 1/4"-28 | 3/8" | 0.125" | 0.063" | 1/8" | 10 | $17.35 | Add to Order |
| SSS-2249 | 5/16"-18 | 3/8" | 0.188" | 0.094" | 5/32" | 10 | $21.00 | Add to Order |
| SSS-2250 | 5/16"-18 | 1/2" | 0.188" | 0.094" | 5/32" | 10 | $21.38 | Add to Order |
| SSS-2251 | 3/8"-16 | 1/2" | 0.188" | 0.094" | 3/16" | 5 | $9.36 | Add to Order |
| SSS-2638 | 3/8"-16 | 3/4" | 0.188" | 0.094" | 3/16" | 5 | $28.27 | Add to Order |
| Rev. 10-23, 04-23, 01-23, 12-22 | ||||||||
