18-8 Stainless Steel Oval Head Slotted Drive Machine Screws
Machine Screws - Oval Head Slotted Drive, Class 2A, *fully threaded, 82° bevel under head with decorative rounded top, for use in countersunk holes.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
| Stainless Steel Slotted Oval Head Machine Screws ASME B18.6.3,80,000 PSI Tensile, FT |
||||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Oval Top Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-3031 | 4-40 | 1/4" | 0.212" | 0.104" | 0.037" | 100 | $9.16 | Add to Order |
| MSS-3125 | 4-40 | 3/8" | 0.212" | 0.104" | 0.037" | 100 | $9.58 | Add to Order |
| MSS-3035 | 4-40 | 1/2" | 0.212" | 0.104" | 0.037" | 100 | $10.46 | Add to Order |
| MSS-3036 | 4-40 | 3/4" | 0.212" | 0.104" | 0.037" | 100 | $11.42 | Add to Order |
| MSS-3037 | 4-40 | 1" | 0.212" | 0.104" | 0.037" | 100 | $14.14 | Add to Order |
| MSS-3038 | 6-32 | 1/4" | 0.262" | 0.128" | 0.045" | 100 | $9.14 | Add to Order |
| MSS-3039 | 6-32 | 5/16" | 0.262" | 0.128" | 0.045" | 100 | $9.72 | Add to Order |
| MSS-3040 | 6-32 | 3/8" | 0.262" | 0.128" | 0.045" | 100 | $10.06 | Add to Order |
| MSS-3041 | 6-32 | 7/16" | 0.262" | 0.128" | 0.045" | 100 | $10.54 | Add to Order |
| MSS-3042 | 6-32 | 1/2" | 0.262" | 0.128" | 0.045" | 100 | $10.64 | Add to Order |
| MSS-3056 | 6-32 | 5/8" | 0.262" | 0.128" | 0.045" | 100 | $11.38 | Add to Order |
| MSS-3044 | 6-32 | 3/4" | 0.262" | 0.128" | 0.045" | 100 | $11.82 | Add to Order |
| MSS-3033 | 6-32 | 1" | 0.262" | 0.128" | 0.045" | 100 | $14.48 | Add to Order |
| MSS-3046 | 6-32 | 1 1/4" | 0.262" | 0.128" | 0.045" | 100 | $19.86 | Add to Order |
| MSS-3047 | 6-32 | 1 1/2" | 0.262" | 0.128" | 0.045" | 100 | $17.00 | Add to Order |
| MSS-3048 | 6-32 | 2" | 0.262" | 0.128" | 0.045" | 50 | $19.00 | Add to Order |
| MSS-3049 | 8-32 | 1/4" | 0.312" | 0.123" | 0.052" | 100 | $10.80 | Add to Order |
| MSS-3050 | 8-32 | 3/8" | 0.312" | 0.152" | 0.052" | 100 | $11.30 | Add to Order |
| MSS-3051 | 8-32 | 1/2" | 0.312" | 0.152" | 0.052" | 100 | $12.24 | Add to Order |
| MSS-3052 | 8-32 | 3/4" | 0.312" | 0.152" | 0.052" | 100 | $14.38 | Add to Order |
| MSS-3053 | 8-32 | 1" | 0.312" | 0.152" | 0.052" | 100 | $18.64 | Add to Order |
| MSS-3054 | 8-32 | 1 1/4" | 0.312" | 0.152" | 0.052" | 50 | $11.84 | Add to Order |
| MSS-3022 | 8-32 | 1 1/2" | 0.312" | 0.152" | 0.052" | 50 | $12.22 | Add to Order |
| MSS-3065 | 10-24 | 3/8" | 0.362" | 0.176" | 0.060" | 100 | $14.24 | Add to Order |
| MSS-3079 | 10-24 | 1/2" | 0.362" | 0.176" | 0.060" | 100 | $19.40 | Add to Order |
| MSS-3068 | 10-24 | 5/8" | 0.362" | 0.176" | 0.060" | 50 | $9.74 | Add to Order |
| MSS-3057 | 10-24 | 3/4" | 0.362" | 0.176" | 0.060" | 50 | $10.38 | Add to Order |
| MSS-3070 | 10-24 | 1" | 0.362" | 0.176" | 0.060" | 50 | $12.38 | Add to Order |
| MSS-3071 | 10-24 | 1 1/4" | 0.362" | 0.176" | 0.060" | 50 | $17.78 | Add to Order |
| MSS-3072 | 10-24 | 1 1/2" | 0.362" | 0.176" | 0.060" | 50 | $18.28 | Add to Order |
| MSS-3073 | 10-32 | 3/8" | 0.362" | 0.176" | 0.060" | 100 | $14.24 | Add to Order |
| MSS-3074 | 10-32 | 1/2" | 0.362" | 0.176" | 0.060" | 100 | $19.40 | Add to Order |
| MSS-3075 | 10-32 | 5/8" | 0.362" | 0.176" | 0.060" | 50 | $10.12 | Add to Order |
| MSS-3076 | 10-32 | 3/4" | 0.362" | 0.176" | 0.060" | 50 | $11.08 | Add to Order |
| MSS-3077 | 10-32 | 1" | 0.362" | 0.176" | 0.060" | 50 | $13.46 | Add to Order |
| MSS-3222 | 10-32 | 1 1/4" | 0.362" | 0.176" | 0.060" | 50 | $19.66 | Add to Order |
| MSS-3034 | 10-32 | 1 1/2" | 0.362" | 0.176" | 0.060" | 50 | $18.28 | Add to Order |
| MSS-3196 | 12-24 | 3/8" | 0.412" | 0.161" | 0.068" | 50 | $12.72 | Add to Order |
| MSS-3316 | 12-24 | 1/2" | 0.412" | 0.200" | 0.068" | 50 | $15.62 | Add to Order |
| MSS-10756 | 12-24 | 11/16" | 0.412" | 0.200" | 0.068" | 50 | $14.72 | Add to Order |
| MSS-3317 | 12-24 | 1" | 0.412" | 0.200" | 0.068" | 25 | $11.32 | Add to Order |
| MSS-3318 | 12-24 | 1 1/4" | 0.412" | 0.200" | 0.068" | 25 | $15.00 | Add to Order |
| MSS-3319 | 1/4"-20 | 1/2" | 0.477" | 0.232" | 0.079" | 50 | $15.94 | Add to Order |
| MSS-3320 | 1/4"-20 | 5/8" | 0.477" | 0.232" | 0.079" | 50 | $15.22 | Add to Order |
| MSS-3321 | 1/4"-20 | 3/4" | 0.477" | 0.232" | 0.079" | 25 | $11.26 | Add to Order |
| MSS-3322 | 1/4"-20 | 1" | 0.477" | 0.232" | 0.079" | 25 | $13.38 | Add to Order |
| MSS-3323 | 1/4"-20 | 1 1/4" | 0.477" | 0.232" | 0.079" | 25 | $15.34 | Add to Order |
| MSS-3324 | 1/4"-20 | 1 1/2" | 0.477" | 0.232" | 0.079" | 25 | $13.78 | Add to Order |
| MSS-3338 | 1/4"-20 | 2" | 0.477" | 0.232" | 0.079" | 25 | $18.82 | Add to Order |
| MSS-3326 | 1/4"-20 | 2 1/2" PT | 0.477" | 0.232" | 0.079" | 10 | $10.38 | Add to Order |
