18-8 Stainless Steel Oval Head Phillips Machine Screws
Machine Screws - Oval Head Phillips Drive, Class 2A, *fully threaded, 82° beveled head, decorative round top, for use in countersunk holes.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
| 18-8 Stainless Steel Passivated Phillips Oval Head Machine
Screws Full threads, unless noted. PT threads have over 1.50" of thread length |
||||||||||
| Part # | Thread Size | Length | Type | Head Dia. | Head Height | Oval Top Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|---|
| MSS-3620 | 2-56 | 1/8" | Undercut | 0.162" | 0.065" | 0.029" | No. 1 | 100 | $10.25 | Add to Order |
| MSS-3608 | 2-56 | 3/16" | Standard | 0.162" | 0.08" | 0.029" | No. 1 | 100 | $9.72 | Add to Order |
| MSS-3597 | 2-56 | 1/4" | Standard | 0.162" | 0.08" | 0.029" | No. 1 | 100 | $9.74 | Add to Order |
| MSS-3610 | 2-56 | 5/16" | Standard | 0.162" | 0.08" | 0.029" | No. 1 | 100 | $9.81 | Add to Order |
| MSS-3611 | 2-56 | 3/8" | Standard | 0.162" | 0.08" | 0.029" | No. 1 | 100 | $9.93 | Add to Order |
| MSS-3612 | 2-56 | 1/2" | Standard | 0.162" | 0.08" | 0.029" | No. 1 | 100 | $10.50 | Add to Order |
| MSS-3613 | 2-56 | 5/8" | Standard | 0.162" | 0.08" | 0.029" | No. 1 | 100 | $10.52 | Add to Order |
| MSS-3614 | 2-56 | 3/4" | Standard | 0.162" | 0.08" | 0.029" | No. 1 | 100 | $11.03 | Add to Order |
| MSS-3615 | 4-40 | 1/8" | Undercut | 0.212" | 0.084" | 0.037" | No. 1 | 100 | $17.72 | Add to Order |
| MSS-3616 | 4-40 | 3/16" | Undercut | 0.212" | 0.084" | 0.037" | No. 1 | 100 | $9.43 | Add to Order |
| MSS-3617 | 4-40 | 1/4" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $6.15 | Add to Order |
| MSS-3618 | 4-40 | 5/16" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $7.64 | Add to Order |
| MSS-3586 | 4-40 | 3/8" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $7.73 | Add to Order |
| MSS-3609 | 4-40 | 7/16" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $8.36 | Add to Order |
| MSS-3607 | 4-40 | 1/2" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $8.02 | Add to Order |
| MSS-3576 | 4-40 | 5/8" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $9.87 | Add to Order |
| MSS-3577 | 4-40 | 3/4" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $10.50 | Add to Order |
| MSS-3578 | 4-40 | 1" | Standard | 0.212" | 0.104" | 0.037" | No. 1 | 100 | $12.24 | Add to Order |
| MSS-3579 | 6-32 | 3/16" | Undercut | 0.262" | 0.104" | 0.045" | No. 2 | 100 | $15.69 | Add to Order |
| MSS-3581 | 6-32 | 1/4" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $6.15 | Add to Order |
| MSS-3582 | 6-32 | 5/16" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $8.90 | Add to Order |
| MSS-3583 | 6-32 | 3/8" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $8.93 | Add to Order |
| MSS-3596 | 6-32 | 7/16" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $10.75 | Add to Order |
| MSS-3585 | 6-32 | 1/2" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $6.57 | Add to Order |
| MSS-3574 | 6-32 | 5/8" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $6.09 | Add to Order |
| MSS-3587 | 6-32 | 3/4" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $5.96 | Add to Order |
| MSS-3192 | 6-32 | 7/8" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $14.70 | Add to Order |
| MSS-3193 | 6-32 | 1" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $12.08 | Add to Order |
| MSS-3194 | 6-32 | 1 1/4" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $17.39 | Add to Order |
| MSS-3195 | 6-32 | 1 1/2" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $16.65 | Add to Order |
| MSS-3163 | 6-32 | 1 3/4" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $21.55 | Add to Order |
| MSS-3184 | 6-32 | 2" | Standard | 0.262" | 0.128" | 0.045" | No. 2 | 100 | $10.94 | Add to Order |
| MSS-3152 | 8-32 | 1/4" | Undercut | 0.312" | 0.123" | 0.052" | No. 2 | 100 | $6.36 | Add to Order |
| MSS-3153 | 8-32 | 5/16" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $14.68 | Add to Order |
| MSS-3154 | 8-32 | 3/8" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $10.08 | Add to Order |
| MSS-3155 | 8-32 | 7/16" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $15.40 | Add to Order |
| MSS-3156 | 8-32 | 1/2" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $15.08 | Add to Order |
| MSS-3157 | 8-32 | 5/8" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $10.50 | Add to Order |
| MSS-3158 | 8-32 | 3/4" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $17.87 | Add to Order |
| MSS-3159 | 8-32 | 7/8" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $16.44 | Add to Order |
| MSS-3160 | 8-32 | 1" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $11.87 | Add to Order |
| MSS-3173 | 8-32 | 1 1/4" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $20.87 | Add to Order |
| MSS-3162 | 8-32 | 1 1/2" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 100 | $24.49 | Add to Order |
| MSS-3151 | 8-32 | 1 3/4" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 50 | $20.77 | Add to Order |
| MSS-3164 | 8-32 | 2" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 50 | $23.08 | Add to Order |
| MSS-3165 | 8-32 | 2 1/2" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 50 | $28.50 | Add to Order |
| MSS-3166 | 8-32 | 3" | Standard | 0.312" | 0.152" | 0.052" | No. 2 | 50 | $23.77 | Add to Order |
| MSS-3167 | 10-24 | 5/16" | Undercut | 0.362" | 0.142" | 0.06" | No. 2 | 100 | $17.49 | Add to Order |
| MSS-3168 | 10-24 | 3/8" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $7.10 | Add to Order |
| MSS-3169 | 10-24 | 7/16" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $18.82 | Add to Order |
| MSS-3170 | 10-24 | 1/2" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $12.94 | Add to Order |
| MSS-3171 | 10-24 | 5/8" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $9.83 | Add to Order |
| MSS-3172 | 10-24 | 3/4" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $27.41 | Add to Order |
| MSS-3102 | 10-24 | 7/8" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $25.89 | Add to Order |
| MSS-3045 | 10-24 | 1" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $21.27 | Add to Order |
| MSS-3043 | 10-24 | 1 1/4" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $23.52 | Add to Order |
| MSS-3011 | 10-24 | 1 1/2" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $23.77 | Add to Order |
| MSS-3012 | 10-24 | 1 3/4" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $29.99 | Add to Order |
| MSS-3013 | 10-24 | 2" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $14.83 | Add to Order |
| MSS-3014 | 10-24 | 2 1/4" PT | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 25 | $19.07 | Add to Order |
| MSS-3015 | 10-24 | 2 1/2" PT | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 25 | $20.18 | Add to Order |
| MSS-3016 | 10-24 | 3" PT | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 25 | $25.24 | Add to Order |
| MSS-3017 | 10-24 | 3 1/2" PT | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 10 | $12.68 | Add to Order |
| MSS-3018 | 10-24 | 4" PT | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 10 | $15.12 | Add to Order |
| MSS-10416 | 10-32 | 1/4" | Undercut | 0.382" | 0.176" | 0.06" | No. 2 | 100 | $12.22 | Add to Order |
| MSS-3019 | 10-32 | 5/16" | Undercut | 0.362" | 0.142" | 0.06" | No. 2 | 100 | $30.09 | Add to Order |
| MSS-3032 | 10-32 | 3/8" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $20.03 | Add to Order |
| MSS-3021 | 10-32 | 7/16" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $19.05 | Add to Order |
| MSS-3010 | 10-32 | 1/2" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $19.87 | Add to Order |
| MSS-3023 | 10-32 | 5/8" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $24.00 | Add to Order |
| MSS-3024 | 10-32 | 3/4" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $22.26 | Add to Order |
| MSS-3025 | 10-32 | 7/8" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $25.89 | Add to Order |
| MSS-3026 | 10-32 | 1" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 100 | $26.75 | Add to Order |
| MSS-3027 | 10-32 | 1 1/4" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $23.52 | Add to Order |
| MSS-3028 | 10-32 | 1 1/2" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $23.77 | Add to Order |
| MSS-3030 | 10-32 | 1 3/4" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 50 | $30.37 | Add to Order |
| MSS-3067 | 10-32 | 2" | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 25 | $16.95 | Add to Order |
| MSS-3020 | 10-32 | 2 1/2" PT | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 25 | $19.01 | Add to Order |
| MSS-3055 | 10-32 | 3" PT | Standard | 0.362" | 0.176" | 0.06" | No. 2 | 25 | $25.24 | Add to Order |
| MSS-3081 | 12-24 | 1/2" | Standard | 0.412" | 0.2" | 0.068" | No. 3 | 50 | $26.25 | Add to Order |
| MSS-3082 | 12-24 | 3/4" | Standard | 0.412" | 0.2" | 0.068" | No. 3 | 50 | $21.48 | Add to Order |
| MSS-3083 | 12-24 | 1" | Standard | 0.412" | 0.2" | 0.068" | No. 3 | 50 | $24.91 | Add to Order |
| MSS-3084 | 12-24 | 1 1/4" | Standard | 0.412" | 0.2" | 0.068" | No. 3 | 50 | $28.35 | Add to Order |
| MSS-3085 | 12-24 | 1 1/2" | Standard | 0.412" | 0.2" | 0.068" | No. 3 | 25 | $16.53 | Add to Order |
| MSS-3086 | 1/4"-20 | 3/8" | Undercut | 0.477" | 0.186" | 0.079" | No. 3 | 50 | $18.90 | Add to Order |
| MSS-3087 | 1/4"-20 | 1/2" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 50 | $20.45 | Add to Order |
| MSS-3088 | 1/4"-20 | 5/8" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 50 | $22.20 | Add to Order |
| MSS-3103 | 1/4"-20 | 3/4" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 50 | $26.33 | Add to Order |
| MSS-10417 | 1/4"-20 | 7/8" | Standard | 0.507" | 0.232" | 0.079" | No. 3 | 100 | $55.48 | Add to Order |
| MSS-3091 | 1/4"-20 | 1" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 25 | $17.18 | Add to Order |
| MSS-3080 | 1/4"-20 | 1 1/4" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 25 | $16.80 | Add to Order |
| MSS-3093 | 1/4"-20 | 1 1/2" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 25 | $19.11 | Add to Order |
| MSS-3094 | 1/4"-20 | 1 3/4" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 25 | $25.43 | Add to Order |
| MSS-3095 | 1/4"-20 | 2" | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 25 | $26.12 | Add to Order |
| MSS-3096 | 1/4"-20 | 2 1/4" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 10 | $11.68 | Add to Order |
| MSS-3097 | 1/4"-20 | 2 1/2" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 10 | $13.17 | Add to Order |
| MSS-3098 | 1/4"-20 | 2 3/4" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 10 | $13.38 | Add to Order |
| MSS-3099 | 1/4"-20 | 3" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 10 | $18.92 | Add to Order |
| MSS-3100 | 1/4"-20 | 3 1/2" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 10 | $20.50 | Add to Order |
| MSS-3101 | 1/4"-20 | 4" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 10 | $21.69 | Add to Order |
| MSS-3069 | 1/4"-20 | 4 1/2" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 5 | $13.38 | Add to Order |
| MSS-3092 | 1/4"-20 | 5" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 5 | $18.50 | Add to Order |
| MSS-3090 | 1/4"-20 | 6" PT | Standard | 0.477" | 0.232" | 0.079" | No. 3 | 5 | $18.14 | Add to Order |
| MSS-10418 | 5/16"-18 | 1/2" | Standard | 0.635" | 0.29" | 0.099" | No. 4 | 50 | $32.19 | Add to Order |
| MSS-10419 | 5/16"-18 | 5/8" | Standard | 0.635" | 0.29" | 0.099" | No. 4 | 50 | $24.70 | Add to Order |
| MSS-3058 | 5/16"-18 | 3/4" | Standard | 0.597" | 0.29" | 0.099" | No. 4 | 10 | $10.56 | Add to Order |
| MSS-3059 | 5/16"-18 | 1" | Standard | 0.597" | 0.29" | 0.099" | No. 4 | 10 | $11.17 | Add to Order |
| MSS-3060 | 5/16"-18 | 1 1/4" | Standard | 0.597" | 0.29" | 0.099" | No. 4 | 10 | $13.19 | Add to Order |
| MSS-3061 | 5/16"-18 | 1 1/2" | Standard | 0.597" | 0.29" | 0.099" | No. 4 | 10 | $12.47 | Add to Order |
| MSS-3062 | 5/16"-18 | 2" | Standard | 0.597" | 0.29" | 0.099" | No. 4 | 10 | $14.03 | Add to Order |
| MSS-3063 | 5/16"-18 | 2 1/2" PT | Standard | 0.597" | 0.29" | 0.099" | No. 4 | 10 | $10.98 | Add to Order |
| MSS-3064 | 5/16"-18 | 3" PT | Standard | 0.597" | 0.29" | 0.099" | No. 4 | 5 | $11.97 | Add to Order |
| MSS-10420 | 3/8"-16 | 1" | Standard | 0.762" | 0.347" | 0.117" | No. 4 | 25 | $34.10 | Add to Order |
| MSS-10421 | 3/8"-16 | 1 1/4" | Standard | 0.762" | 0.347" | 0.117" | No. 4 | 25 | $25.12 | Add to Order |
| MSS-10422 | 3/8"-16 | 1 1/2" | Standard | 0.762" | 0.347" | 0.117" | No. 4 | 25 | $29.57 | Add to Order |
| MSS-10423 | 3/8"-16 | 2" | Standard | 0.762" | 0.347" | 0.117" | No. 4 | 10 | $15.06 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | ||||||||||
