18-8 Stainless Steel Oval Head Phillips Metric Machine Screws
Machine Screws - Oval Head Phillips Drive, Class 6g, DIN 966, fully threaded, 90° beveled head, decorative rounded top, for use in countersunk holes.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
| Metric
Phillips Oval Head Machine Screws 18-8 Stainless Steel DIN 966, 70,000 PSI Tensile, FT |
||||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height. (mm) | Oval Top Height (mm) | Drive | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|---|
| MSS-10430 | M2.5 | 0.45 mm | 5 | 4.7 | 2.1 | 0.6 | No. 1 | 100 | $17.18 | Add to Order |
| MSS-3296 | M2.5 | 0.45 mm | 6 | 4.7 | 2.1 | 0.6 | No. 1 | 100 | $9.09 | Add to Order |
| MSS-3297 | M2.5 | 0.45 mm | 8 | 4.7 | 2.1 | 0.6 | No. 1 | 50 | $16.09 | Add to Order |
| MSS-3298 | M2.5 | 0.45 mm | 10 | 4.7 | 2.1 | 0.6 | No. 1 | 50 | $10.65 | Add to Order |
| MSS-3299 | M2.5 | 0.45 mm | 12 | 4.7 | 2.1 | 0.6 | No. 1 | 50 | $2.98 | Add to Order |
| MSS-3300 | M3 | 0.5 mm | 5 | 5.6 | 2.4 | 0.75 | No. 1 | 50 | $27.24 | Add to Order |
| MSS-3301 | M3 | 0.5 mm | 6 | 5.6 | 2.4 | 0.75 | No. 1 | 100 | $8.57 | Add to Order |
| MSS-3314 | M3 | 0.5 mm | 8 | 5.6 | 2.4 | 0.75 | No. 1 | 100 | $8.93 | Add to Order |
| MSS-3303 | M3 | 0.5 mm | 10 | 5.6 | 2.4 | 0.75 | No. 1 | 100 | $10.42 | Add to Order |
| MSS-3292 | M3 | 0.5 mm | 12 | 5.6 | 2.4 | 0.75 | No. 1 | 100 | $18.90 | Add to Order |
| MSS-3305 | M3 | 0.5 mm | 16 | 5.6 | 2.4 | 0.75 | No. 1 | 100 | $16.11 | Add to Order |
| MSS-3306 | M3 | 0.5 mm | 20 | 5.6 | 2.4 | 0.75 | No. 1 | 100 | $16.30 | Add to Order |
| MSS-3307 | M4 | 0.7 mm | 6 | 7.5 | 3.2 | 1 | No. 2 | 100 | $23.10 | Add to Order |
| MSS-3308 | M4 | 0.7 mm | 8 | 7.5 | 3.2 | 1 | No. 2 | 100 | $13.48 | Add to Order |
| MSS-3309 | M4 | 0.7 mm | 10 | 7.5 | 3.2 | 1 | No. 2 | 100 | $12.96 | Add to Order |
| MSS-3310 | M4 | 0.7 mm | 12 | 7.5 | 3.2 | 1 | No. 2 | 100 | $13.42 | Add to Order |
| MSS-3311 | M4 | 0.7 mm | 16 | 7.5 | 3.2 | 1 | No. 2 | 100 | $17.12 | Add to Order |
| MSS-3312 | M4 | 0.7 mm | 20 | 7.5 | 3.2 | 1 | No. 2 | 100 | $30.89 | Add to Order |
| MSS-3349 | M4 | 0.7 mm | 25 | 7.5 | 3.2 | 1 | No. 2 | 50 | $25.16 | Add to Order |
| MSS-3302 | M4 | 0.7 mm | 30 | 7.5 | 3.2 | 1 | No. 2 | 25 | $8.51 | Add to Order |
| MSS-10431 | M5 | 0.8 mm | 8 | 9.2 | 3.75 | 1.25 | No. 2 | 100 | $29.57 | Add to Order |
| MSS-3337 | M5 | 0.8 mm | 10 | 9.2 | 3.75 | 1.25 | No. 2 | 100 | $18.59 | Add to Order |
| MSS-3363 | M5 | 0.8 mm | 12 | 9.2 | 3.75 | 1.25 | No. 2 | 50 | $24.04 | Add to Order |
| MSS-3364 | M5 | 0.8 mm | 16 | 9.2 | 3.75 | 1.25 | No. 2 | 50 | $28.31 | Add to Order |
| MSS-3365 | M5 | 0.8 mm | 20 | 9.2 | 3.75 | 1.25 | No. 2 | 50 | $29.95 | Add to Order |
| MSS-3366 | M5 | 0.8 mm | 25 | 9.2 | 3.75 | 1.25 | No. 2 | 50 | $25.85 | Add to Order |
| MSS-3367 | M5 | 0.8 mm | 30 | 9.2 | 3.75 | 1.25 | No. 2 | 25 | $15.20 | Add to Order |
| MSS-3368 | M5 | 0.8 mm | 35 | 9.2 | 3.75 | 1.25 | No. 2 | 25 | $26.73 | Add to Order |
| MSS-3369 | M6 | 1 mm | 10 | 11 | 4.5 | 1.5 | No. 3 | 50 | $34.36 | Add to Order |
| MSS-3370 | M6 | 1 mm | 12 | 11 | 4.5 | 1.5 | No. 3 | 50 | $17.03 | Add to Order |
| MSS-3371 | M6 | 1 mm | 16 | 11 | 4.5 | 1.5 | No. 3 | 50 | $41.10 | Add to Order |
| MSS-3385 | M6 | 1 mm | 20 | 11 | 4.5 | 1.5 | No. 3 | 25 | $21.34 | Add to Order |
| MSS-3373 | M6 | 1 mm | 25 | 11 | 4.5 | 1.5 | No. 3 | 25 | $24.47 | Add to Order |
| MSS-3362 | M6 | 1 mm | 30 | 11 | 4.5 | 1.5 | No. 3 | 25 | $14.11 | Add to Order |
| MSS-3375 | M6 | 1 mm | 35 | 11 | 4.5 | 1.5 | No. 3 | 25 | $20.50 | Add to Order |
| MSS-10432 | M8 | 1.25 mm | 16 | 14.5 | 6 | 2 | No. 3 | 100 | $29.57 | Add to Order |
| MSS-3376 | M8 | 1.25 mm | 20 | 14.5 | 6 | 2 | No. 4 | 25 | $18.04 | Add to Order |
| MSS-3377 | M8 | 1.25 mm | 25 | 14.5 | 6 | 2 | No. 4 | 25 | $24.30 | Add to Order |
| MSS-3378 | M8 | 1.25 mm | 30 | 14.5 | 6 | 2 | No. 4 | 10 | $22.81 | Add to Order |
| Rev. 03-24, 10-23, 02-23, 11-22 | ||||||||||
