18-8 Stainless Binding Head Slotted Drive Steel Machine Screws
Machine Screws - Binding Head Slotted Drive, Class 2A, *fully threaded, large flat bearing surface, ideal for electrical connections, thick round head and tapered sides.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
| 18-8 Stainless Steel Binding Head Slotted Machine Screws 100,000 PSI Tensile, ASME B18.6.3, FT |
|||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-728 | 0-80 | 1/8" | 0.126" | 0.032" | 100 | $21.08 | Add to Order |
| MSS-717 | 0-80 | 3/16" | 0.126" | 0.032" | 100 | $21.21 | Add to Order |
| MSS-706 | 0-80 | 1/4" | 0.126" | 0.032" | 100 | $25.14 | Add to Order |
| MSS-719 | 0-80 | 5/16" | 0.126" | 0.032" | 100 | $26.94 | Add to Order |
| MSS-720 | 0-80 | 3/8" | 0.126" | 0.032" | 100 | $29.67 | Add to Order |
| MSS-721 | 0-80 | 1/2" | 0.126" | 0.032" | 50 | $18.19 | Add to Order |
| MSS-722 | 0-80 | 3/4" | 0.126" | 0.032" | 50 | $25.60 | Add to Order |
| MSS-723 | 1-72 | 5/16" | 0.153" | 0.041" | 50 | $13.94 | Add to Order |
| MSS-724 | 1-72 | 1/2" | 0.153" | 0.041" | 50 | $18.31 | Add to Order |
| MSS-725 | 2-56 | 1/8" | 0.181" | 0.050" | 100 | $3.23 | Add to Order |
| MSS-587 | 2-56 | 3/16" | 0.181" | 0.050" | 100 | $3.32 | Add to Order |
| MSS-576 | 2-56 | 1/4" | 0.181" | 0.050" | 100 | $3.57 | Add to Order |
| MSS-565 | 2-56 | 5/16" | 0.181" | 0.050" | 100 | $3.89 | Add to Order |
| MSS-578 | 2-56 | 3/8" | 0.181" | 0.050" | 100 | $5.17 | Add to Order |
| MSS-579 | 2-56 | 7/16" | 0.181" | 0.050" | 100 | $4.64 | Add to Order |
| MSS-580 | 2-56 | 1/2" | 0.181" | 0.050" | 100 | $5.59 | Add to Order |
| MSS-581 | 2-56 | 5/8" | 0.181" | 0.050" | 100 | $13.42 | Add to Order |
| MSS-582 | 2-56 | 3/4" | 0.181" | 0.050" | 100 | $15.56 | Add to Order |
| MSS-583 | 2-56 | 7/8" | 0.181" | 0.050" | 100 | $16.09 | Add to Order |
| MSS-584 | 2-56 | 1" | 0.181" | 0.050" | 100 | $16.88 | Add to Order |
| MSS-585 | 2-56 | 1 1/4" | 0.181" | 0.050" | 50 | $21.86 | Add to Order |
| MSS-622 | 2-56 | 1 1/2" | 0.181" | 0.050" | 50 | $27.15 | Add to Order |
| MSS-575 | 3-48 | 3/16" | 0.208" | 0.059" | 100 | $17.75 | Add to Order |
| MSS-610 | 3-48 | 1/4" | 0.208" | 0.059" | 100 | $16.51 | Add to Order |
| MSS-636 | 3-48 | 3/8" | 0.208" | 0.059" | 100 | $18.12 | Add to Order |
| MSS-637 | 3-48 | 1/2" | 0.208" | 0.059" | 100 | $19.99 | Add to Order |
| MSS-638 | 3-48 | 3/4" | 0.208" | 0.059" | 50 | $14.57 | Add to Order |
| MSS-639 | 3-48 | 7/8" | 0.208" | 0.059" | 50 | $18.27 | Add to Order |
| MSS-640 | 3-48 | 1" | 0.208" | 0.059" | 50 | $18.63 | Add to Order |
| MSS-641 | 4-40 | 1/8" | 0.235" | 0.068" | 100 | $3.19 | Add to Order |
| MSS-642 | 4-40 | 3/16" | 0.235" | 0.068" | 100 | $3.72 | Add to Order |
| MSS-643 | 4-40 | 1/4" | 0.235" | 0.068" | 100 | $3.99 | Add to Order |
| MSS-644 | 4-40 | 5/16" | 0.235" | 0.068" | 100 | $5.25 | Add to Order |
| MSS-658 | 4-40 | 3/8" | 0.235" | 0.068" | 100 | $4.58 | Add to Order |
| MSS-649 | 4-40 | 7/16" | 0.235" | 0.068" | 100 | $12.02 | Add to Order |
| MSS-635 | 4-40 | 1/2" | 0.235" | 0.068" | 100 | $6.15 | Add to Order |
| MSS-648 | 4-40 | 9/16" | 0.235" | 0.068" | 100 | $5.17 | Add to Order |
| MSS-649B | 4-40 | 5/8" | 0.235" | 0.068" | 100 | $6.89 | Add to Order |
| MSS-650 | 4-40 | 3/4" | 0.235" | 0.068" | 100 | $5.73 | Add to Order |
| MSS-651 | 4-40 | 7/8" | 0.235" | 0.068" | 100 | $17.96 | Add to Order |
| MSS-652 | 4-40 | 1" | 0.235" | 0.068" | 100 | $9.37 | Add to Order |
| MSS-653 | 4-40 | 1 1/4" | 0.235" | 0.068" | 100 | $23.79 | Add to Order |
| MSS-654 | 4-40 | 1 1/2" | 0.235" | 0.068" | 100 | $13.10 | Add to Order |
| MSS-655 | 5-40 | 3/16" | 0.263" | 0.078" | 100 | $17.83 | Add to Order |
| MSS-656 | 5-40 | 1/4" | 0.263" | 0.078" | 100 | $15.29 | Add to Order |
| MSS-624 | 5-40 | 5/16" | 0.263" | 0.078" | 100 | $15.92 | Add to Order |
| MSS-647 | 5-40 | 3/8" | 0.263" | 0.078" | 100 | $17.09 | Add to Order |
| MSS-645 | 5-40 | 1/2" | 0.263" | 0.078" | 100 | $17.47 | Add to Order |
| MSS-613 | 5-40 | 1" | 0.263" | 0.078" | 100 | $23.79 | Add to Order |
| MSS-614 | 6-32 | 1/8" | 0.290" | 0.087" | 100 | $21.25 | Add to Order |
| MSS-615 | 6-32 | 3/16" | 0.290" | 0.087" | 100 | $11.13 | Add to Order |
| MSS-616 | 6-32 | 1/4" | 0.290" | 0.087" | 100 | $5.84 | Add to Order |
| MSS-617 | 6-32 | 5/16" | 0.290" | 0.087" | 100 | $15.75 | Add to Order |
| MSS-618 | 6-32 | 3/8" | 0.290" | 0.087" | 100 | $5.15 | Add to Order |
| MSS-726 | 6-32 | 7/16" | 0.290" | 0.087" | 100 | $4.24 | Add to Order |
| MSS-727 | 6-32 | 1/2" | 0.290" | 0.087" | 100 | $6.30 | Add to Order |
| MSS-657 | 6-32 | 5/8" | 0.290" | 0.087" | 100 | $7.18 | Add to Order |
| MSS-586 | 6-32 | 3/4" | 0.290" | 0.087" | 100 | $8.15 | Add to Order |
| MSS-680 | 6-32 | 7/8" | 0.290" | 0.087" | 100 | $9.03 | Add to Order |
| MSS-590 | 6-32 | 1" | 0.290" | 0.087" | 100 | $9.87 | Add to Order |
| MSS-591 | 6-32 | 1 1/4" | 0.290" | 0.087" | 100 | $10.29 | Add to Order |
| MSS-592 | 6-32 | 1 1/2" | 0.290" | 0.087" | 50 | $18.61 | Add to Order |
| MSS-593 | 6-32 | 1 3/4" | 0.290" | 0.087" | 50 | $20.92 | Add to Order |
| MSS-594 | 6-32 | 2" | 0.290" | 0.087" | 50 | $23.21 | Add to Order |
| MSS-595 | 8-32 | 3/16" | 0.344" | 0.105" | 100 | $7.81 | Add to Order |
| MSS-619 | 8-32 | 1/4" | 0.344" | 0.105" | 100 | $6.03 | Add to Order |
| MSS-620 | 8-32 | 5/16" | 0.344" | 0.105" | 100 | $6.53 | Add to Order |
| MSS-621 | 8-32 | 3/8" | 0.344" | 0.105" | 100 | $7.67 | Add to Order |
| MSS-634 | 8-32 | 7/16" | 0.344" | 0.105" | 100 | $22.95 | Add to Order |
| MSS-623 | 8-32 | 1/2" | 0.344" | 0.105" | 100 | $8.02 | Add to Order |
| MSS-612 | 8-32 | 5/8" | 0.344" | 0.105" | 100 | $10.12 | Add to Order |
| MSS-625 | 8-32 | 3/4" | 0.344" | 0.105" | 100 | $16.44 | Add to Order |
| MSS-626 | 8-32 | 7/8" | 0.344" | 0.105" | 100 | $27.15 | Add to Order |
| MSS-627 | 8-32 | 1" | 0.344" | 0.105" | 100 | $15.83 | Add to Order |
| MSS-628 | 8-32 | 1 1/4" | 0.344" | 0.105" | 100 | $14.74 | Add to Order |
| MSS-629 | 8-32 | 1 1/2" | 0.344" | 0.105" | 50 | $19.40 | Add to Order |
| MSS-630 | 8-32 | 1 3/4" | 0.344" | 0.105" | 50 | $23.04 | Add to Order |
| MSS-631 | 8-32 | 2" | 0.344" | 0.105" | 50 | $24.82 | Add to Order |
| MSS-633 | 10-24 | 1/4" | 0.399" | 0.123" | 100 | $24.26 | Add to Order |
| MSS-375 | 10-24 | 3/8" | 0.399" | 0.123" | 100 | $10.65 | Add to Order |
| MSS-069 | 10-24 | 1/2" | 0.399" | 0.123" | 100 | $34.50 | Add to Order |
| MSS-445 | 10-24 | 5/8" | 0.399" | 0.123" | 50 | $19.85 | Add to Order |
| MSS-120 | 10-24 | 3/4" | 0.399" | 0.123" | 100 | $14.30 | Add to Order |
| MSS-121 | 10-24 | 1" | 0.399" | 0.123" | 50 | $27.28 | Add to Order |
| MSS-122 | 10-24 | 1 1/4" | 0.399" | 0.123" | 50 | $27.47 | Add to Order |
| MSS-123 | 10-24 | 1 1/2" | 0.399" | 0.123" | 25 | $16.95 | Add to Order |
| MSS-564 | 10-24 | 2" | 0.399" | 0.123" | 25 | $20.41 | Add to Order |
| MSS-552 | 10-32 | 1/4" | 0.399" | 0.123" | 100 | $16.91 | Add to Order |
| MSS-541 | 10-32 | 5/16" | 0.399" | 0.123" | 100 | $16.91 | Add to Order |
| MSS-554 | 10-32 | 3/8" | 0.399" | 0.123" | 100 | $29.02 | Add to Order |
| MSS-555 | 10-32 | 1/2" | 0.399" | 0.123" | 100 | $35.72 | Add to Order |
| MSS-556 | 10-32 | 5/8" | 0.399" | 0.123" | 50 | $20.37 | Add to Order |
| MSS-557 | 10-32 | 3/4" | 0.399" | 0.123" | 50 | $20.08 | Add to Order |
| MSS-558 | 10-32 | 1" | 0.399" | 0.123" | 100 | $53.89 | Add to Order |
| MSS-559 | 10-32 | 1 1/4" | 0.399" | 0.123" | 25 | $14.81 | Add to Order |
| MSS-560 | 10-32 | 1 1/2" | 0.399" | 0.123" | 25 | $16.55 | Add to Order |
| MSS-561 | 10-32 | 2" | 0.399" | 0.123" | 25 | $20.22 | Add to Order |
| MSS-562 | 12-24 | 1/2" | 0.454" | 0.141" | 50 | $26.46 | Add to Order |
| MSS-530 | 12-24 | 5/8" | 0.454" | 0.141" | 50 | $26.80 | Add to Order |
| MSS-553 | 12-24 | 3/4" | 0.454" | 0.141" | 50 | $27.36 | Add to Order |
| MSS-551 | 12-24 | 1" | 0.454" | 0.141" | 50 | $29.46 | Add to Order |
| MSS-519 | 1/4"-20 | 3/8" | 0.525" | 0.165" | 25 | $11.42 | Add to Order |
| MSS-520 | 1/4"-20 | 1/2" | 0.525" | 0.165" | 50 | $15.44 | Add to Order |
| MSS-521 | 1/4"-20 | 5/8" | 0.525" | 0.165" | 25 | $16.74 | Add to Order |
| MSS-522 | 1/4"-20 | 3/4" | 0.525" | 0.165" | 25 | $17.72 | Add to Order |
| MSS-523 | 1/4"-20 | 1" | 0.525" | 0.165" | 50 | $14.83 | Add to Order |
| MSS-524 | 1/4"-20 | 1 1/4" | 0.525" | 0.165" | 25 | $19.66 | Add to Order |
| MSS-525 | 1/4"-20 | 1 1/2" | 0.525" | 0.165" | 25 | $21.76 | Add to Order |
| MSS-6100 | 1/4"-20 | 2" | 0.525" | 0.165" | 10 | $10.82 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||
