Nylon 6/6 Binding Head Slotted Machine Screws
Machine Screws - Binding Head Slotted, Class 2A, fully threaded.
Nylon 6/6 - Non conductive, chemical and solvent resistant, except mineral acids. Temperature range -40°/+185°F. Absorbs moisture which can affect dimensions and properties. Off white.
| Plastic Binding Head Slotted Machine Screws Full Threads |
|||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-9539 | 0-80 | 1/8" | 0.126" | 0.032" | 100 | $30.56 | Add to Order |
| MSS-9540 | 0-80 | 3/16" | 0.126" | 0.032" | 100 | $31.67 | Add to Order |
| MSS-9541 | 0-80 | 1/4" | 0.126" | 0.032" | 100 | $32.84 | Add to Order |
| MSS-2702 | 2-56 | 3/32" | 0.181" | 0.050" | 100 | $22.24 | Add to Order |
| MSS-2993 | 2-56 | 1/8" | 0.181" | 0.050" | 100 | $20.69 | Add to Order |
| MSS-2871 | 2-56 | 3/16" | 0.181" | 0.050" | 100 | $20.81 | Add to Order |
| MSS-2351 | 2-56 | 1/4" | 0.181" | 0.050" | 100 | $20.92 | Add to Order |
| MSS-2407 | 2-56 | 5/16" | 0.181" | 0.050" | 100 | $21.17 | Add to Order |
| MSS-2269 | 2-56 | 3/8" | 0.181" | 0.050" | 100 | $21.29 | Add to Order |
| MSS-2488 | 2-56 | 7/16" | 0.181" | 0.050" | 100 | $21.40 | Add to Order |
| MSS-5906 | 2-56 | 1/2" | 0.181" | 0.050" | 100 | $21.40 | Add to Order |
| MSS-4851 | 2-56 | 3/4" | 0.181" | 0.050" | 100 | $21.67 | Add to Order |
| MSS-3575 | 2-56 | 1" | 0.181" | 0.050" | 100 | $21.88 | Add to Order |
| MSS-3182 | 4-40 | 3/16" | 0.235" | 0.068" | 100 | $20.81 | Add to Order |
| MSS-3174 | 4-40 | 1/4" | 0.235" | 0.068" | 100 | $20.92 | Add to Order |
| MSS-3190 | 4-40 | 9/32" | 0.235" | 0.068" | 100 | $21.04 | Add to Order |
| MSS-3066 | 4-40 | 5/16" | 0.235" | 0.068" | 100 | $21.17 | Add to Order |
| MSS-3211 | 4-40 | 3/8" | 0.235" | 0.068" | 100 | $21.29 | Add to Order |
| MSS-3256 | 4-40 | 1/2" | 0.235" | 0.068" | 100 | $21.40 | Add to Order |
| MSS-4297 | 4-40 | 5/8" | 0.235" | 0.068" | 100 | $21.53 | Add to Order |
| MSS-4230 | 4-40 | 3/4" | 0.235" | 0.068" | 100 | $21.76 | Add to Order |
| MSS-4494 | 4-40 | 1" | 0.235" | 0.068" | 100 | $21.88 | Add to Order |
| MSS-4498 | 6-32 | 3/16" | 0.290" | 0.087" | 100 | $21.53 | Add to Order |
| MSS-4490 | 6-32 | 1/4" | 0.290" | 0.087" | 100 | $21.76 | Add to Order |
| MSS-5582 | 6-32 | 3/8" | 0.290" | 0.087" | 100 | $22.01 | Add to Order |
| MSS-5580 | 6-32 | 1/2" | 0.290" | 0.087" | 100 | $22.11 | Add to Order |
| MSS-4471 | 6-32 | 5/8" | 0.290" | 0.087" | 100 | $22.24 | Add to Order |
| MSS-4475 | 6-32 | 3/4" | 0.290" | 0.087" | 100 | $22.49 | Add to Order |
| MSS-4467 | 6-32 | 1" | 0.290" | 0.087" | 100 | $22.60 | Add to Order |
| MSS-4483 | 8-32 | 1/4" | 0.344" | 0.105" | 100 | $22.60 | Add to Order |
| MSS-4487 | 8-32 | 3/8" | 0.344" | 0.105" | 100 | $22.72 | Add to Order |
| MSS-4441 | 8-32 | 1/2" | 0.344" | 0.105" | 100 | $22.85 | Add to Order |
| MSS-4354 | 8-32 | 5/8" | 0.344" | 0.105" | 100 | $22.85 | Add to Order |
| MSS-4359 | 8-32 | 3/4" | 0.344" | 0.105" | 100 | $16.46 | Add to Order |
| MSS-4362 | 8-32 | 1" | 0.344" | 0.105" | 100 | $23.08 | Add to Order |
| MSS-4366 | 8-32 | 1 1/4" | 0.344" | 0.105" | 100 | $23.56 | Add to Order |
| MSS-4370 | 8-32 | 1 1/2" | 0.344" | 0.105" | 100 | $23.92 | Add to Order |
| MSS-4327 | 10-24 | 1/4" | 0.399" | 0.123" | 100 | $24.04 | Add to Order |
| MSS-4331 | 10-24 | 1/2" | 0.399" | 0.123" | 100 | $24.51 | Add to Order |
| MSS-4335 | 10-24 | 3/4" | 0.399" | 0.123" | 100 | $24.86 | Add to Order |
| MSS-3879 | 10-24 | 1" | 0.399" | 0.123" | 100 | $24.99 | Add to Order |
| MSS-4339 | 10-24 | 1 1/2" | 0.399" | 0.123" | 100 | $25.47 | Add to Order |
| MSS-4383 | 10-32 | 1/4" | 0.399" | 0.123" | 100 | $24.04 | Add to Order |
| MSS-4402 | 10-32 | 1/2" | 0.399" | 0.123" | 100 | $24.51 | Add to Order |
| MSS-4407 | 10-32 | 5/8" | 0.399" | 0.123" | 100 | $24.63 | Add to Order |
| MSS-4411 | 10-32 | 3/4" | 0.399" | 0.123" | 100 | $24.86 | Add to Order |
| MSS-4415 | 10-32 | 1" | 0.399" | 0.123" | 100 | $24.99 | Add to Order |
| MSS-4408 | 10-32 | 1 1/2" | 0.399" | 0.123" | 100 | $25.47 | Add to Order |
| MSS-4376 | 10-32 | 2" | 0.399" | 0.123" | 100 | $28.22 | Add to Order |
| MSS-4380 | 1/4"-20 | 1/4" | 0.525" | 0.165" | 100 | $27.38 | Add to Order |
| MSS-9542 | 1/4"-20 | 3/8" | 0.525" | 0.165" | 100 | $15.48 | Add to Order |
| MSS-4384 | 1/4"-20 | 1/2" | 0.525" | 0.165" | 100 | $27.74 | Add to Order |
| MSS-4388 | 1/4"-20 | 5/8" | 0.525" | 0.165" | 100 | $27.87 | Add to Order |
| MSS-4392 | 1/4"-20 | 3/4" | 0.525" | 0.165" | 100 | $27.97 | Add to Order |
| MSS-3830 | 1/4"-20 | 1" | 0.525" | 0.165" | 100 | $28.22 | Add to Order |
| MSS-3883 | 1/4"-20 | 1 1/2" | 0.525" | 0.165" | 100 | $49.05 | Add to Order |
| MSS-3887 | 1/4"-20 | 2" | 0.525" | 0.165" | 100 | $31.69 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||
