Lag Screws - Zinc Plated Steel
| Zinc Plated Steel, Partially Threaded, ASME B18.2.1 | |||||||||
| Part # | Thread Size | Length | Head Width | Head Heigth | Threads per (in.) | Minimum Thread Lg. | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| LAG-750 | 1/4" | 1" | 0.438" | 0.172" | 10 | 0.667" | 100 | $12.88 | Add to Order |
| LAG-751 | 1/4" | 1 1/4" | 0.438" | 0.172" | 10 | 0.833" | 100 | $14.20 | Add to Order |
| LAG-752 | 1/4" | 1 1/2" | 0.438" | 0.172" | 10 | 1" | 100 | $16.56 | Add to Order |
| LAG-753 | 1/4" | 1 3/4" | 0.438" | 0.172" | 10 | 1.167" | 100 | $22.44 | Add to Order |
| LAG-754 | 1/4" | 2" | 0.438" | 0.172" | 10 | 1.333" | 100 | $25.04 | Add to Order |
| LAG-755 | 1/4" | 2 1/2" | 0.438" | 0.172" | 10 | 1.667" | 100 | $26.06 | Add to Order |
| LAG-756 | 1/4" | 3" | 0.438" | 0.172" | 10 | 2" | 50 | $16.08 | Add to Order |
| LAG-757 | 1/4" | 3 1/2" | 0.438" | 0.172" | 10 | 2.333" | 100 | $18.08 | Add to Order |
| LAG-758 | 1/4" | 4" | 0.438" | 0.172" | 10 | 2.667" | 50 | $21.88 | Add to Order |
| LAG-759 | 1/4" | 5" | 0.438" | 0.172" | 10 | 3.333" | 50 | $25.88 | Add to Order |
| LAG-760 | 1/4" | 6" | 0.438" | 0.172" | 10 | 4" | 25 | $16.48 | Add to Order |
| LAG-761 | 5/16" | 1" | 0.5" | 0.219" | 9 | 0.667" | 100 | $20.94 | Add to Order |
| LAG-762 | 5/16" | 1 1/4" | 0.5" | 0.219" | 9 | 0.833" | 100 | $23.40 | Add to Order |
| LAG-763 | 5/16" | 1 1/2" | 0.5" | 0.219" | 9 | 1" | 100 | $28.06 | Add to Order |
| LAG-764 | 5/16" | 1 3/4" | 0.5" | 0.219" | 9 | 1.167" | 50 | $15.90 | Add to Order |
| LAG-765 | 5/16" | 2" | 0.5" | 0.219" | 9 | 1.333" | 50 | $16.76 | Add to Order |
| LAG-766 | 5/16" | 2 1/2" | 0.5" | 0.219" | 9 | 1.667" | 50 | $20.48 | Add to Order |
| LAG-767 | 5/16" | 3" | 0.5" | 0.219" | 9 | 2" | 50 | $24.80 | Add to Order |
| LAG-768 | 5/16" | 3 1/2" | 0.5" | 0.219" | 9 | 2.333" | 50 | $28.24 | Add to Order |
| LAG-769 | 5/16" | 4" | 0.5" | 0.219" | 9 | 2.667" | 50 | $17.72 | Add to Order |
| LAG-770 | 5/16" | 5" | 0.5" | 0.219" | 9 | 3.333" | 50 | $20.06 | Add to Order |
| LAG-1326Z | 5/16" | 6" | 0.5" | 0.219" | 9 | 4" | 25 | $24.72 | Add to Order |
| LAG-771 | 3/8" | 1" | 0.563" | 0.25" | 7 | 0.667" | 50 | $16.68 | Add to Order |
| LAG-772 | 3/8" | 1 1/4" | 0.563" | 0.25" | 7 | 0.833" | 50 | $16.86 | Add to Order |
| LAG-773 | 3/8" | 1 1/2" | 0.563" | 0.25" | 7 | 1" | 50 | $18.94 | Add to Order |
| LAG-774 | 3/8" | 1 3/4" | 0.563" | 0.25" | 7 | 1.167" | 50 | $24.30 | Add to Order |
| LAG-775 | 3/8" | 2" | 0.563" | 0.25" | 7 | 1.333" | 50 | $26.18 | Add to Order |
| LAG-776 | 3/8" | 2 1/2" | 0.563" | 0.25" | 7 | 1.667" | 25 | $15.42 | Add to Order |
| LAG-777 | 3/8" | 3" | 0.563" | 0.25" | 7 | 2" | 50 | $16.16 | Add to Order |
| LAG-778 | 3/8" | 3 1/2" | 0.563" | 0.25" | 7 | 2.333" | 25 | $18.82 | Add to Order |
| LAG-779 | 3/8" | 4" | 0.563" | 0.25" | 7 | 2.667" | 25 | $21.10 | Add to Order |
| LAG-780 | 3/8" | 4 1/2" | 0.563" | 0.25" | 7 | 3" | 25 | $25.12 | Add to Order |
| LAG-781 | 3/8" | 5" | 0.563" | 0.25" | 7 | 3.333" | 25 | $26.26 | Add to Order |
| LAG-782 | 3/8" | 6" | 0.563" | 0.25" | 7 | 4" | 10 | $14.14 | Add to Order |
| LAG-783 | 3/8" | 7" | 0.563" | 0.25" | 7 | 4" | 10 | $16.88 | Add to Order |
| LAG-784 | 3/8" | 8" | 0.563" | 0.25" | 7 | 4" | 5 | $9.18 | Add to Order |
| LAG-785 | 1/2" | 1 1/2" | 0.75" | 0.344" | 6 | 1" | 25 | $20.38 | Add to Order |
| LAG-786 | 1/2" | 2" | 0.75" | 0.344" | 6 | 1.333" | 25 | $25.24 | Add to Order |
| LAG-787 | 1/2" | 2 1/2" | 0.75" | 0.344" | 6 | 1.667" | 10 | $12.72 | Add to Order |
| LAG-788 | 1/2" | 3" | 0.75" | 0.344" | 6 | 2" | 10 | $13.72 | Add to Order |
| LAG-789 | 1/2" | 3 1/2" | 0.75" | 0.344" | 6 | 2.333" | 10 | $13.56 | Add to Order |
| LAG-790 | 1/2" | 4" | 0.75" | 0.344" | 6 | 2.667" | 5 | $7.06 | Add to Order |
| LAG-791 | 1/2" | 4 1/2" | 0.75" | 0.344" | 6 | 3" | 10 | $19.18 | Add to Order |
| LAG-792 | 1/2" | 5" | 0.75" | 0.344" | 6 | 3.333" | 10 | $19.62 | Add to Order |
| LAG-793 | 1/2" | 6" | 0.75" | 0.344" | 6 | 4" | 10 | $25.10 | Add to Order |
| LAG-794 | 1/2" | 7" | 0.75" | 0.344" | 6 | 4" | 10 | $28.08 | Add to Order |
| LAG-795 | 1/2" | 8" | 0.75" | 0.344" | 6 | 4" | 5 | $16.12 | Add to Order |
| LAG-796 | 5/8" | 3" | 0.938" | 0.422" | 5 | 2" | 5 | $13.26 | Add to Order |
| LAG-797 | 5/8" | 4" | 0.938" | 0.422" | 5 | 2.667" | 5 | $14.54 | Add to Order |
| LAG-798 | 5/8" | 5" | 0.938" | 0.422" | 5 | 3.333" | 5 | $18.36 | Add to Order |
| LAG-799 | 5/8" | 7" | 0.938" | 0.422" | 5 | 4" | 1 | $5.22 | Add to Order |
| LAG-800 | 3/4" | 3" | 1.125" | 0.5" | 4.5 | 2" | 5 | $23.80 | Add to Order |
| LAG-801 | 3/4" | 4" | 1.125" | 0.5" | 4.5 | 2.667" | 5 | $25.58 | Add to Order |
| LAG-802 | 3/4" | 5" | 1.125" | 0.5" | 4.5 | 3.333" | 5 | $26.30 | Add to Order |
| LAG-803 | 3/4" | 6" | 1.125" | 0.5" | 4.5 | 4" | 1 | $5.98 | Add to Order |
| Rev. 02-22, 06-21 | |||||||||
