Lag Screws - 316 Stainless Steel
| 316 Stainless Lag Screws, PT, ASME B18.2.1 | |||||||||
| Part # | Thread Size |
Length | Head Width |
Head Height |
Threads Per Inch |
Min. Thread Length |
Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| LAG-307 | 1/4" | 1" | 0.438" | 0.172" | 10 | 0.667" | 25 | $18.43 | Add to Order |
| LAG-1349 | 1/4" | 1 1/4" | 0.438" | 0.172" | 10 | 0.833" | 10 | $11.97 | Add to Order |
| LAG-308 | 1/4" | 1 1/2" | 0.438" | 0.172" | 10 | 1" | 10 | $10.56 | Add to Order |
| LAG-309 | 1/4" | 2" | 0.438" | 0.172" | 10 | 1.333" | 10 | $12.67 | Add to Order |
| LAG-310 | 1/4" | 2 1/2" | 0.438" | 0.172" | 10 | 1.667" | 10 | $15.44 | Add to Order |
| LAG-311 | 1/4" | 3" | 0.438" | 0.172" | 10 | 2" | 10 | $16.15 | Add to Order |
| LAG-1350 | 1/4" | 3 1/2" | 0.438" | 0.172" | 10 | 2.333" | 5 | $12.92 | Add to Order |
| LAG-1351 | 1/4" | 4" | 0.438" | 0.172" | 10 | 2.667" | 5 | $14.78 | Add to Order |
| LAG-1352 | 1/4" | 4 1/2" | 0.438" | 0.172" | 10 | 3" | 5 | $17.36 | Add to Order |
| LAG-1353 | 1/4" | 5" | 0.438" | 0.172" | 10 | 3.333" | 5 | $18.24 | Add to Order |
| LAG-1354 | 1/4" | 6" | 0.438" | 0.172" | 10 | 4" | 1 | $4.28 | Add to Order |
| LAG-1355 | 5/16" | 1" | 0.5" | 0.219" | 9 | 0.667" | 10 | $16.95 | Add to Order |
| LAG-1356 | 5/16" | 1 1/4" | 0.5" | 0.219" | 9 | 0.833" | 10 | $18.24 | Add to Order |
| LAG-312 | 5/16" | 1 1/2" | 0.5" | 0.219" | 9 | 1" | 10 | $17.08 | Add to Order |
| LAG-313 | 5/16" | 2" | 0.5" | 0.219" | 9 | 1.333" | 10 | $18.49 | Add to Order |
| LAG-314 | 5/16" | 2 1/2" | 0.5" | 0.219" | 9 | 1.667" | 5 | $12.07 | Add to Order |
| LAG-315 | 5/16" | 3" | 0.5" | 0.219" | 9 | 2" | 5 | $14.45 | Add to Order |
| LAG-316 | 5/16" | 3 1/2" | 0.5" | 0.219" | 9 | 2.333" | 5 | $16.36 | Add to Order |
| LAG-317 | 5/16" | 4" | 0.5" | 0.219" | 9 | 2.667" | 5 | $16.81 | Add to Order |
| LAG-1357 | 5/16" | 4 1/2" | 0.5" | 0.219" | 9 | 3" | 1 | $5.13 | Add to Order |
| LAG-1358 | 5/16" | 5" | 0.5" | 0.219" | 9 | 3.333" | 1 | $5.58 | Add to Order |
| LAG-1359 | 5/16" | 6" | 0.5" | 0.219" | 9 | 4" | 1 | $6.85 | Add to Order |
| LAG-1360 | 3/8" | 1" | 0.563" | 0.25" | 7 | 0.667" | 5 | $11.44 | Add to Order |
| LAG-1361 | 3/8" | 1 1/4" | 0.563" | 0.25" | 7 | 0.833" | 5 | $13.49 | Add to Order |
| LAG-318 | 3/8" | 1 1/2" | 0.563" | 0.25" | 7 | 1" | 10 | $22.45 | Add to Order |
| LAG-319 | 3/8" | 2" | 0.563" | 0.25" | 7 | 1.333" | 5 | $15.54 | Add to Order |
| LAG-320 | 3/8" | 2 1/2" | 0.563" | 0.25" | 7 | 1.667" | 5 | $15.42 | Add to Order |
| LAG-321 | 3/8" | 3" | 0.563" | 0.25" | 7 | 2" | 5 | $19.04 | Add to Order |
| LAG-322 | 3/8" | 3 1/2" | 0.563" | 0.25" | 7 | 2.333" | 1 | $4.06 | Add to Order |
| LAG-323 | 3/8" | 4" | 0.563" | 0.25" | 7 | 2.667" | 1 | $4.24 | Add to Order |
| LAG-1362 | 3/8" | 4 1/2" | 0.563" | 0.25" | 7 | 3" | 1 | $7.15 | Add to Order |
| LAG-1363 | 3/8" | 5" | 0.563" | 0.25" | 7 | 3.333" | 1 | $7.95 | Add to Order |
| LAG-1364 | 3/8" | 6" | 0.563" | 0.25" | 7 | 4" | 1 | $9.72 | Add to Order |
| LAG-1365 | 3/8" | 7" | 0.563" | 0.25" | 7 | 4.667" | 1 | $27.49 | Add to Order |
| LAG-1366 | 3/8" | 8" | 0.563" | 0.25" | 7 | 4" | 1 | $28.78 | Add to Order |
| LAG-1367 | 3/8" | 10" | 0.563" | 0.25" | 7 | 4" | 1 | $32.33 | Add to Order |
| LAG-1368 | 1/2" | 1 1/2" | 0.75" | 0.344" | 6 | 1" | 1 | $6.01 | Add to Order |
| LAG-324 | 1/2" | 2" | 0.75" | 0.344" | 6 | 1.333" | 1 | $4.49 | Add to Order |
| LAG-325 | 1/2" | 2 1/2" | 0.75" | 0.344" | 6 | 1.667" | 1 | $6.09 | Add to Order |
| LAG-326 | 1/2" | 3" | 0.75" | 0.344" | 6 | 2" | 1 | $6.97 | Add to Order |
| LAG-327 | 1/2" | 3 1/2" | 0.75" | 0.344" | 6 | 2.333" | 1 | $7.09 | Add to Order |
| LAG-328 | 1/2" | 4" | 0.75" | 0.344" | 6 | 2.667" | 1 | $8.65 | Add to Order |
| LAG-1369 | 1/2" | 4 1/2" | 0.75" | 0.344" | 6 | 3" | 1 | $14.21 | Add to Order |
| LAG-1370 | 1/2" | 5" | 0.75" | 0.344" | 6 | 3.333" | 1 | $15.01 | Add to Order |
| LAG-1371 | 1/2" | 6" | 0.75" | 0.344" | 6 | 4" | 1 | $17.59 | Add to Order |
| LAG-1372 | 1/2" | 7" | 0.75" | 0.344" | 6 | 4.667" | 1 | $35.26 | Add to Order |
| LAG-1373 | 1/2" | 8" | 0.75" | 0.344" | 6 | 4" | 1 | $37.21 | Add to Order |
| LAG-1374 | 1/2" | 10" | 0.75" | 0.344" | 6 | 4" | 1 | $36.53 | Add to Order |
| LAG-1375 | 1/2" | 12" | 0.75" | 0.344" | 6 | 4" | 1 | $43.99 | Add to Order |
| LAG-1376 | 5/8" | 2 1/2" | 0.938" | 0.422" | 5 | 1.667" | 1 | $37.21 | Add to Order |
| LAG-1377 | 5/8" | 3" | 0.938" | 0.422" | 5 | 2" | 1 | $37.54 | Add to Order |
| LAG-1378 | 5/8" | 4" | 0.938" | 0.422" | 5 | 2.667" | 1 | $39.79 | Add to Order |
| LAG-1379 | 5/8" | 5" | 0.938" | 0.422" | 5 | 3.333" | 1 | $42.37 | Add to Order |
| LAG-1380 | 5/8" | 6" | 0.938" | 0.422" | 5 | 4" | 1 | $45.31 | Add to Order |
| LAG-1381 | 5/8" | 7" | 0.938" | 0.422" | 5 | 4.667" | 1 | $48.22 | Add to Order |
| LAG-1382 | 5/8" | 8" | 0.938" | 0.422" | 5 | 4" | 1 | $51.46 | Add to Order |
| LAG-1383 | 5/8" | 10" | 0.938" | 0.422" | 5 | 4" | 1 | $59.86 | Add to Order |
| LAG-1384 | 3/4" | 4" | 1.125" | 0.5" | 4.5 | 2.667" | 1 | $78.31 | Add to Order |
| LAG-1385 | 3/4" | 5" | 1.125" | 0.5" | 4.5 | 3.333" | 1 | $70.56 | Add to Order |
| LAG-1386 | 3/4" | 6" | 1.125" | 0.5" | 4.5 | 4" | 1 | $142.50 | Add to Order |
| LAG-1387 | 3/4" | 7" | 1.125" | 0.5" | 4.5 | 4.667" | 1 | $82.66 | Add to Order |
| LAG-1388 | 3/4" | 8" | 1.125" | 0.5" | 4.5 | 5.333" | 1 | $94.75 | Add to Order |
| LAG-1389 | 3/4" | 10" | 1.125" | 0.5" | 4.5 | 4" | 1 | $94.44 | Add to Order |
| LAG-1390 | 3/4" | 12" | 1.125" | 0.5" | 4.5 | 4" | 1 | $112.50 | Add to Order |
| Rev. 01-23, 06-21 | |||||||||
