Lag Screws - 18-8 Stainless Steel
| 18-8 Stainless Steel Lag Screws, Partially Threaded, ASME B18.2.1 |
|||||||||
| Part # | Thread Size | Length | Head Width | Head Heigth | Threads per (in.) | Minimum Thread Lg. | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| LAG-132 | 1/4" | 1" | 0.438" | 0.172" | 10 | 0.667" | 50 | $43.42 | Add to Order |
| LAG-133 | 1/4" | 1 1/4" | 0.438" | 0.172" | 10 | 0.833" | 25 | $18.94 | Add to Order |
| LAG-134 | 1/4" | 1 1/2" | 0.438" | 0.172" | 10 | 1" | 25 | $11.36 | Add to Order |
| LAG-135 | 1/4" | 1 3/4" | 0.438" | 0.172" | 10 | 1.167" | 25 | $24.29 | Add to Order |
| LAG-136 | 1/4" | 2" | 0.438" | 0.172" | 10 | 1.333" | 25 | $27.20 | Add to Order |
| LAG-137 | 1/4" | 2 1/2" | 0.438" | 0.172" | 10 | 1.667" | 25 | $31.94 | Add to Order |
| LAG-138 | 1/4" | 3" | 0.438" | 0.172" | 10 | 2" | 10 | $16.32 | Add to Order |
| LAG-139 | 1/4" | 3 1/2" | 0.438" | 0.172" | 10 | 2.333" | 10 | $10.40 | Add to Order |
| LAG-140 | 1/4" | 4" | 0.438" | 0.172" | 10 | 2.667" | 10 | $20.13 | Add to Order |
| LAG-141 | 1/4" | 4 1/2" | 0.438" | 0.172" | 10 | 3" | 10 | $22.12 | Add to Order |
| LAG-142 | 1/4" | 5" | 0.438" | 0.172" | 10 | 3.333" | 10 | $20.19 | Add to Order |
| LAG-143 | 1/4" | 6" | 0.438" | 0.172" | 10 | 4" | 10 | $26.90 | Add to Order |
| LAG-144 | 5/16" | 1" | 0.5" | 0.219" | 9 | 0.667" | 25 | $22.16 | Add to Order |
| LAG-145 | 5/16" | 1 1/4" | 0.5" | 0.219" | 9 | 0.833" | 25 | $26.20 | Add to Order |
| LAG-146 | 5/16" | 1 1/2" | 0.5" | 0.219" | 9 | 1" | 25 | $16.14 | Add to Order |
| LAG-147 | 5/16" | 1 3/4" | 0.5" | 0.219" | 9 | 1.167" | 10 | $15.27 | Add to Order |
| LAG-148 | 5/16" | 2" | 0.5" | 0.219" | 9 | 1.333" | 25 | $20.56 | Add to Order |
| LAG-149 | 5/16" | 2 1/2" | 0.5" | 0.219" | 9 | 1.667" | 10 | $18.29 | Add to Order |
| LAG-150 | 5/16" | 3" | 0.5" | 0.219" | 9 | 2" | 10 | $19.39 | Add to Order |
| LAG-151 | 5/16" | 3 1/2" | 0.5" | 0.219" | 9 | 2.333" | 10 | $21.59 | Add to Order |
| LAG-152 | 5/16" | 4" | 0.5" | 0.219" | 9 | 2.667" | 10 | $24.11 | Add to Order |
| LAG-153 | 5/16" | 4 1/2" | 0.5" | 0.219" | 9 | 3" | 10 | $31.30 | Add to Order |
| LAG-154 | 5/16" | 5" | 0.5" | 0.219" | 9 | 3.333" | 5 | $18.22 | Add to Order |
| LAG-155 | 5/16" | 6" | 0.5" | 0.219" | 9 | 4" | 5 | $21.14 | Add to Order |
| LAG-156 | 3/8" | 1" | 0.563" | 0.25" | 7 | 0.667" | 10 | $15.23 | Add to Order |
| LAG-157 | 3/8" | 1 1/4" | 0.563" | 0.25" | 7 | 0.833" | 10 | $17.04 | Add to Order |
| LAG-158 | 3/8" | 1 1/2" | 0.563" | 0.25" | 7 | 1" | 10 | $18.22 | Add to Order |
| LAG-159 | 3/8" | 1 3/4" | 0.563" | 0.25" | 7 | 1.167" | 10 | $20.97 | Add to Order |
| LAG-160 | 3/8" | 2" | 0.563" | 0.25" | 7 | 1.333" | 10 | $22.57 | Add to Order |
| LAG-161 | 3/8" | 2 1/2" | 0.563" | 0.25" | 7 | 1.667" | 10 | $15.64 | Add to Order |
| LAG-162 | 3/8" | 3" | 0.563" | 0.25" | 7 | 2" | 10 | $31.88 | Add to Order |
| LAG-163 | 3/8" | 3 1/2" | 0.563" | 0.25" | 7 | 2.333" | 10 | $29.27 | Add to Order |
| LAG-164 | 3/8" | 4" | 0.563" | 0.25" | 7 | 2.667" | 5 | $22.39 | Add to Order |
| LAG-165 | 3/8" | 4 1/2" | 0.563" | 0.25" | 7 | 3" | 10 | $30.42 | Add to Order |
| LAG-166 | 3/8" | 5" | 0.563" | 0.25" | 7 | 3.333" | 5 | $25.40 | Add to Order |
| LAG-167 | 3/8" | 6" | 0.563" | 0.25" | 7 | 4" | 5 | $30.44 | Add to Order |
| LAG-1339 | 3/8" | 7" | 0.563" | 0.25" | 7 | 4.667" | 1 | $32.02 | Add to Order |
| LAG-1340 | 3/8" | 8" | 0.563" | 0.25" | 7 | 5.333" | 1 | $18.96 | Add to Order |
| LAG-1341 | 3/8" | 10" | 0.563" | 0.25" | 7 | 4" | 1 | $26.81 | Add to Order |
| LAG-168 | 1/2" | 1 1/2" | 0.75" | 0.344" | 6 | 1" | 5 | $19.02 | Add to Order |
| LAG-169 | 1/2" | 2" | 0.75" | 0.344" | 6 | 1.333" | 5 | $19.27 | Add to Order |
| LAG-170 | 1/2" | 2 1/2" | 0.75" | 0.344" | 6 | 1.667" | 5 | $23.19 | Add to Order |
| LAG-171 | 1/2" | 3" | 0.75" | 0.344" | 6 | 2" | 5 | $23.43 | Add to Order |
| LAG-172 | 1/2" | 3 1/2" | 0.75" | 0.344" | 6 | 2.333" | 1 | $5.43 | Add to Order |
| LAG-173 | 1/2" | 4" | 0.75" | 0.344" | 6 | 2.667" | 1 | $6.05 | Add to Order |
| LAG-1342 | 1/2" | 4 1/2" | 0.75" | 0.344" | 6 | 3" | 1 | $6.15 | Add to Order |
| LAG-174 | 1/2" | 5" | 0.75" | 0.344" | 6 | 3.333" | 1 | $6.79 | Add to Order |
| LAG-175 | 1/2" | 6" | 0.75" | 0.344" | 6 | 4" | 1 | $8.34 | Add to Order |
| LAG-1343 | 1/2" | 7" | 0.75" | 0.344" | 6 | 4.667" | 1 | $32.49 | Add to Order |
| LAG-1344 | 1/2" | 8" | 0.75" | 0.344" | 6 | 5.333" | 1 | $33.82 | Add to Order |
| LAG-1345 | 1/2" | 10" | 0.75" | 0.344" | 6 | 4" | 1 | $21.36 | Add to Order |
| LAG-1346 | 1/2" | 12" | 0.75" | 0.344" | 6 | 4" | 1 | $20.60 | Add to Order |
| LAG-176 | 5/8" | 2 1/2" | 0.938" | 0.422" | 5 | 1.667" | 1 | $24.56 | Add to Order |
| LAG-177 | 5/8" | 3" | 0.938" | 0.422" | 5 | 2" | 1 | $25.30 | Add to Order |
| LAG-179 | 5/8" | 4" | 0.938" | 0.422" | 5 | 2.667" | 1 | $27.16 | Add to Order |
| LAG-180 | 5/8" | 5" | 0.938" | 0.422" | 5 | 3.333" | 1 | $28.78 | Add to Order |
| LAG-181 | 5/8" | 6" | 0.938" | 0.422" | 5 | 4" | 1 | $30.57 | Add to Order |
| LAG-182 | 5/8" | 7" | 0.938" | 0.422" | 5 | 4.667" | 1 | $32.39 | Add to Order |
| LAG-183 | 5/8" | 8" | 0.938" | 0.422" | 5 | 5.333" | 1 | $34.15 | Add to Order |
| LAG-184 | 5/8" | 10" | 0.938" | 0.422" | 5 | 4" | 1 | $36.72 | Add to Order |
| LAG-1347 | 5/8" | 12" | 0.938" | 0.422" | 5 | 4" | 1 | $37.74 | Add to Order |
| LAG-1348 | 3/4" | 3" | 1.125" | 0.5" | 4.5 | 2" | 1 | $51.89 | Add to Order |
| LAG-185 | 3/4" | 4" | 1.125" | 0.5" | 4.5 | 2.667" | 1 | $44.18 | Add to Order |
| LAG-186 | 3/4" | 5" | 1.125" | 0.5" | 4.5 | 3.333" | 1 | $60.74 | Add to Order |
| LAG-187 | 3/4" | 6" | 1.125" | 0.5" | 4.5 | 4" | 1 | $65.89 | Add to Order |
| LAG-188 | 3/4" | 7" | 1.125" | 0.5" | 4.5 | 4.667" | 1 | $51.86 | Add to Order |
| LAG-189 | 3/4" | 8" | 1.125" | 0.5" | 4.5 | 5.333" | 1 | $52.93 | Add to Order |
| LAG-190 | 3/4" | 10" | 1.125" | 0.5" | 4.5 | 4" | 1 | $74.66 | Add to Order |
| LAG-191 | 3/4" | 12" | 1.125" | 0.5" | 4.5 | 4" | 1 | $79.09 | Add to Order |
| Rev. 04-23, 01-23, 02-22, 06-21 | |||||||||
