Grade 8 Zinc Plated Serrated Flange Head Bolts
High Strength Zinc Plated Steel, Grade 8, Vibration Resistant, Fully Threaded, RH Threads, SAE J429
| Grade 8 Vibration Resistant Serrated Flange Head Bolts, Zinc Plated | ||||||||
| Part # | Thread Size | Overall Length | Flange Diameter | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-143 | 1/4"-20 | .500" | .562" | 3/8" | 9/32" | 100 | $36.54 | Add to Order |
| Bolt-144 | 1/4"-20 | .750" | .562" | 3/8" | 9/32" | 100 | $45.65 | Add to Order |
| Bolt-145 | 1/4"-20 | 1.00" | .562" | 3/8" | 9/32" | 50 | $31.50 | Add to Order |
| Bolt-146 | 1/4"-20 | 1.25" | .562" | 3/8" | 9/32" | 50 | $26.27 | Add to Order |
| Bolt-147 | 1/4"-20 | 1.50" | .562" | 3/8" | 9/32" | 50 | $35.01 | Add to Order |
| Bolt-148 | 5/16"-18 | .500" | .687" | 5/16" | 21/64" | 50 | $31.92 | Add to Order |
| Bolt-149 | 5/16"-18 | .750" | .687" | 5/16" | 21/64" | 50 | $42.00 | Add to Order |
| Bolt-150 | 5/16"-18 | 1.00" | .687" | 5/16" | 21/64" | 50 | $48.80 | Add to Order |
| Bolt-151 | 5/16"-18 | 1.25" | .687" | 5/16" | 21/64" | 25 | $28.88 | Add to Order |
| Bolt-152 | 5/16"-18 | 1.50" | .687" | 5/16" | 21/64" | 25 | $28.85 | Add to Order |
| Bolt-153 | 5/16"-18 | 1.75" | .687" | 5/16" | 21/64" | 25 | $32.51 | Add to Order |
| Bolt-154 | 5/16"-18 | 2.00" | .687" | 5/16" | 21/64" | 25 | $35.81 | Add to Order |
| Bolt-155 | 3/8"-16 | .750" | .812" | 9/16" | 25/64" | 20 | $25.20 | Add to Order |
| Bolt-156 | 3/8"-16 | .875" | .812" | 9/16" | 25/64" | 20 | $39.90 | Add to Order |
| Bolt-157 | 3/8"-16 | 1.00" | .812" | 9/16" | 25/64" | 20 | $40.99 | Add to Order |
| Bolt-158 | 3/8"-16 | 1.25" | .812" | 9/16" | 25/64" | 20 | $48.05 | Add to Order |
| Bolt-159 | 3/8"-16 | 1.50" | .812" | 9/16" | 25/64" | 20 | $55.27 | Add to Order |
| Bolt-160 | 3/8"-16 | 1.75" | .812" | 9/16" | 25/64" | 20 | $57.46 | Add to Order |
| Bolt-161 | 3/8"-16 | 2.00" | .812" | 9/16" | 25/64" | 20 | $40.19 | Add to Order |
| Rev. 04-23, 11-22, 02-22, 07-21 | ||||||||
