Grade 5 Zinc Plated Steel Flange Head Bolts
Grade 5, RH Threads, SAE J429
| Grade 5 Zinc Plated Steel Flange Head Bolts Fully Threaded | ||||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Flange Diameter | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-5448 | 1/4"-20 | .500" | 3/8" | 9/32" | .5625" | 100 | $39.98 | Add to Order |
| Bolt-5449 | 1/4"-20 | .625" | 3/8" | 9/32" | .5625" | 100 | $32.66 | Add to Order |
| Bolt-5450 | 1/4"-20 | .750" | 3/8" | 9/32" | .5625" | 100 | $35.13 | Add to Order |
| Bolt-5451 | 1/4"-20 | 1.00" | 3/8" | 9/32" | .5625" | 100 | $36.65 | Add to Order |
| Bolt-5452 | 1/4"-20 | 1.25" | 3/8" | 9/32" | .5625" | 100 | $60.02 | Add to Order |
| Bolt-5456 | 5/16"-18 | .500" | 1/2" | 21/64" | .6875" | 50 | $30.01 | Add to Order |
| Bolt-5457 | 5/16"-18 | .625" | 1/2" | 21/64" | .6875" | 50 | $34.96 | Add to Order |
| Bolt-5458 | 5/16"-18 | .750" | 1/2" | 21/64" | .6875" | 50 | $15.04 | Add to Order |
| Bolt-5459 | 5/16"-18 | 1.00" | 1/2" | 21/64" | .6875" | 50 | $50.00 | Add to Order |
| Bolt-5460 | 5/16"-18 | 1.25" | 1/2" | 21/64" | .6875" | 50 | $55.02 | Add to Order |
| Bolt-5464 | 3/8"-16 | .500" | 9/16" | 25/64" | .8125" | 50 | $52.46 | Add to Order |
| Bolt-5465 | 3/8"-16 | .625" | 9/16" | 25/64" | .8125" | 25 | $31.50 | Add to Order |
| Bolt-5466 | 3/8"-16 | .750" | 9/16" | 25/64" | .8125" | 25 | $35.01 | Add to Order |
| Bolt-5467 | 3/8"-16 | 1.00" | 9/16" | 25/64" | .8125" | 25 | $37.51 | Add to Order |
| Bolt-5468 | 3/8"-16 | 1.25" | 9/16" | 25/64" | .8125" | 25 | $42.50 | Add to Order |
| Bolt-5469 | 3/8"-16 | 1.50" | 9/16" | 25/64" | .8125" | 20 | $38.01 | Add to Order |
| Bolt-5472 | 1/2"-13 | 1.00" | 3/4" | 33/64" | 1-5/64" | 20 | $39.02 | Add to Order |
| Bolt-5473 | 1/2"-13 | 1.25" | 3/4" | 33/64" | 1-5/64" | 10 | $34.96 | Add to Order |
| Bolt-5474 | 1/2"-13 | 1.50" | 3/4" | 33/64" | 1-5/64" | 10 | $39.92 | Add to Order |
| Bolt-5475 | 1/2"-13 | 1.75" | 3/4" | 33/64" | 1-5/64" | 10 | $39.00 | Add to Order |
| Rev. 08-23, 04-23, 11-22, 02-22 | ||||||||
| Grade 5 Zinc Plated Steel Flange Head Bolts Partially Threaded | |||||||||
| Part # | Thread Length | Thread Size | Overall Length | Head Width | Head Height | Flange Diameter | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| Bolt-5453 | 3/4" to 1-3/16" | 1/4"-20 | 1.50" | 3/8" | 9/32" | .5625" | 50 | $18.10 | Add to Order |
| Bolt-5454 | 3/4" to 1-3/16" | 1/4"-20 | 1.75" | 3/8" | 9/32" | .5625" | 50 | $39.98 | Add to Order |
| Bolt-5455 | 3/4" to 1-3/16" | 1/4"-20 | 2.00" | 3/8" | 9/32" | .5625" | 50 | $39.98 | Add to Order |
| Bolt-5461 | 7/8" to Full | 5/16"-18 | 1.50" | 1/2" | 21/64" | .6875" | 25 | $27.51 | Add to Order |
| Bolt-5462 | 7/8" to Full | 5/16"-18 | 1.75" | 1/2" | 21/64" | .6875" | 25 | $30.01 | Add to Order |
| Bolt-5463 | 7/8" to 1-15/16" | 5/16"-18 | 2.00" | 1/2" | 21/64" | .6875" | 25 | $32.51 | Add to Order |
| Bolt-5470 | 1" to 1-7/16" | 3/8"-16 | 1.75" | 9/16" | 25/64" | .8125" | 20 | $39.98 | Add to Order |
| Bolt-5471 | 1" to 1-7/16" | 3/8"-16 | 2.00" | 9/16" | 25/64" | .8125" | 20 | $41.96 | Add to Order |
| Bolt-5476 | 1-1/4" to 1-3/4" | 1/2"-13 | 2.00" | 3/4" | 33/64" | 1-5/64" | 10 | $20.10 | Add to Order |
| Bolt-5477 | 1-1/4" to 1-3/4" | 1/2"-13 | 2.50" | 3/4" | 33/64" | 1-5/64" | 10 | $23.04 | Add to Order |
| Rev. 04-23, 11-22, 03-22, 02-22 | |||||||||
