Aluminum Bolts
RH Threads, Fully Threaded
| Aluminum Bolts | |||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| Bolt-4677 | 1/4"-20 | .500" | 7/16" | 5/32" | 25 | $29.06 | Add to Order |
| Bolt-4678 | 1/4"-20 | .750" | 7/16" | 5/32" | 25 | $32.74 | Add to Order |
| Bolt-4679 | 1/4"-20 | 1.00" | 7/16" | 5/32" | 25 | $35.99 | Add to Order |
| Bolt-4680 | 1/4"-20 | 1.25" | 7/16" | 5/32" | 25 | $43.05 | Add to Order |
| Bolt-4681 | 1/4"-20 | 1.50" | 7/16" | 5/32" | 25 | $55.50 | Add to Order |
| Bolt-4682 | 1/4"-20 | 2.00" | 7/16" | 5/32" | 25 | $60.48 | Add to Order |
| Bolt-4683 | 1/4"-20 | 2.50" | 7/16" | 5/32" | 10 | $29.65 | Add to Order |
| Bolt-4684 | 1/4"-20 | 3.00" | 7/16" | 5/32" | 10 | $32.15 | Add to Order |
| Bolt-4685 | 5/16"-18 | .750" | 1/2" | 13/64" | 25 | $58.44 | Add to Order |
| Bolt-4686 | 5/16"-18 | 1.00" | 1/2" | 13/64" | 25 | $59.70 | Add to Order |
| Bolt-4687 | 5/16"-18 | 1.25" | 1/2" | 13/64" | 25 | $66.36 | Add to Order |
| Bolt-4688 | 5/16"-18 | 1.50" | 1/2" | 13/64" | 25 | $70.73 | Add to Order |
| Bolt-4689 | 5/16"-18 | 2.00" | 1/2" | 13/64" | 10 | $44.10 | Add to Order |
| Bolt-4690 | 5/16"-18 | 2.50" | 1/2" | 13/64" | 10 | $50.06 | Add to Order |
| Bolt-4691 | 5/16"-18 | 3.00" | 1/2" | 13/64" | 10 | $62.58 | Add to Order |
| Bolt-4692 | 3/8"-16 | .750" | 9/16" | 15/64" | 25 | $61.38 | Add to Order |
| Bolt-4693 | 3/8"-16 | 1.00" | 9/16" | 15/64" | 25 | $61.64 | Add to Order |
| Bolt-4694 | 3/8"-16 | 1.25" | 9/16" | 15/64" | 10 | $31.77 | Add to Order |
| Bolt-4695 | 3/8"-16 | 1.50" | 9/16" | 15/64" | 25 | $81.54 | Add to Order |
| Bolt-4696 | 3/8"-16 | 2.00" | 9/16" | 15/64" | 10 | $36.90 | Add to Order |
| Bolt-4697 | 3/8"-16 | 3.00" | 9/16" | 15/64" | 10 | $53.09 | Add to Order |
| Bolt-4698 | 1/2"-13 | 1.00" | 3/4" | 5/16" | 10 | $61.61 | Add to Order |
| Bolt-4699 | 1/2"-13 | 1.50" | 3/4" | 5/16" | 5 | $39.90 | Add to Order |
| Bolt-4700 | 1/2"-13 | 2.00" | 3/4" | 5/16" | 5 | $47.78 | Add to Order |
| Bolt-4701 | 1/2"-13 | 2.50" | 3/4" | 5/16" | 5 | $50.51 | Add to Order |
| Bolt-4702 | 1/2"-13 | 3.00" | 3/4" | 5/16" | 5 | $52.29 | Add to Order |
| Bolt-4703 | 1/2"-13 | 3.50" | 3/4" | 5/16" | 5 | $57.75 | Add to Order |
| Bolt-4704 | 1/2"-13 | 4.00" | 3/4" | 5/16" | 5 | $65.73 | Add to Order |
| Bolt-4705 | 5/8"-11 | 1.50" | 15/16" | 25/64" | 5 | $62.37 | Add to Order |
| Bolt-4706 | 5/8"-11 | 2.00" | 15/16" | 25/64" | 5 | $72.98 | Add to Order |
| Bolt-4707 | 5/8"-11 | 2.50" | 15/16" | 25/64" | 5 | $90.41 | Add to Order |
| Bolt-4708 | 5/8"-11 | 3.00" | 15/16" | 25/64" | 5 | $101.01 | Add to Order |
| Rev. 04-23, 11-22, 02-22, 07-21 | |||||||
